AB 1756-ENBT Product Introduction

1756-ENBT is a programmable control system module launched by Rockwell Automation(Allen-Bradley),which belongs to the ControlLogix series.The following is a detailed analysis of the 1756-ENBT module.

Basic attributes

Brand:Rockwell Automation(Allen-Bradley)

Series:ControlLogix

Type:Ethernet communication module

Main functions

Ethernet communication:The 1756-ENBT module supports high-speed Ethernet communication,which can achieve fast data transmission and real-time monitoring.It supports multiple communication protocols,such as TCP/IP,UDP,HTTP,etc.,and can communicate with different types of devices and systems.

Remote access:The module supports remote access function,allowing users to remotely access and monitor the control system through the network,facilitating remote maintenance and diagnosis.

Data processing:The 1756-ENBT module can handle a large amount of data exchange and supports up to 64 TCP and 128 CIP(Common Industrial Protocol)connections.In addition,it also has a high-speed processor interlocking function to control distributed I/O.

Network Integration:The module supports Ethernet/IP network as the backbone routing and can connect to devices on different NetLinx networks to achieve network integration and data sharing.

Technical Specifications

Communication Rate:Supports 10/100 Mbps communication rate to meet the communication needs of industrial environments.

Interface:Has one RJ45 communication port and one USB 1.1 configuration port.

Power Consumption and Heat Dissipation:Power consumption is 3.7 watts and heat dissipation is 12.6 BTU/hour.

Power Supply:Current consumption is 700 mA at 5.1 volts DC and 3 mA at 24 volts DC.

Design Features

Industrial-grade design:The 1756-ENBT module has a durable industrial-grade design that can resist adverse factors such as vibration and temperature changes,and is suitable for use in various industrial environment conditions.

Modular Design:The module adopts a modular design for easy installation,maintenance and upgrade.It is usually installed in the rack of the ControlLogix control system and connected to the main controller through the backplane.

Flexibility:The 1756-ENBT module has flexible configuration options and can be adjusted and customized according to specific application requirements.It can also be seamlessly integrated with Rockwell Automation’s ControlLogix control system and work with other ControlLogix components.
