BENTLY 3500/42M 176449-02 Product Introduction

BENTLY 3500/42M 176449-02 is a vibration monitoring module produced by Bently Nevada,which is part of its rotating machinery monitoring system.The monitor is mainly used to measure the displacement and vibration of mechanical equipment to provide real-time monitoring and evaluation of the health of the equipment.

Main Features

Multi-channel monitoring

This module is a configurable 4-channel monitor module that can monitor multiple parameters simultaneously,improving the efficiency of testing and measurement.

Various input types

In addition to receiving eddy current sensor input types,the module can also receive velocity,acceleration and dual probe(velocity and displacement)input types and their related signal conditioning,such as filtering and integration.

Differential signal processing

The module is capable of differential signal processing to extract the casing vibration signal from the shaft relative vibration,providing key information for absolute shaft measurement of some large gas and steam turbines.

High-precision measurement

The module provides up to 24-bit resolution and low noise level for accurate analog signal measurement.Its excellent linearity and low drift performance ensure accurate measurement results over a wide dynamic range.

Flexible input range

BENTLY 3500/42M 176449-02 supports a variety of adjustable input ranges to adapt to the amplitude requirements of different signal sources,enhancing the flexibility and accuracy of measurement.

Built-in calibration function

The module has a built-in automatic calibration function to ensure the accuracy and reliability of each channel during the measurement process.In addition,it also supports standard calibration procedures to further ensure the consistency and accuracy of measurement results.

Temperature monitoring

The module also has the ability to remotely monitor temperature conditions,providing insights into mechanical thermal performance.

High-speed data transmission

Using the PXIe bus interface,the module is capable of high-speed data transmission,ensuring that the collected data can be quickly transferred to the computer for processing and analysis.

Main functions

Displacement measurement

The monitor can measure the displacement of mechanical equipment,including displacement changes in axial and radial directions.

Vibration monitoring

In addition to displacement,the monitor can also monitor the vibration of mechanical equipment to help evaluate the operating status of the equipment.

Real-time monitoring and alarm

It can monitor the displacement and vibration of the equipment in real time and provide timely alarm and alarm functions to indicate any potential problems or abnormal conditions.

Data storage and analysis

With data storage and analysis functions,it can record historical data and perform trend analysis to help predict the maintenance needs of the equipment.

Fault diagnosis and repair

If the monitor fails or is abnormal,it can perform fault diagnosis and take corresponding repair measures to ensure the normal operation of the equipment.

Application field

BENTLY 3500/42M 176449-02 is widely used in various occasions where the displacement and vibration of mechanical equipment need to be monitored,such as petrochemical,electric power,aerospace,metallurgy and other fields.In these areas,it can effectively monitor and control various production parameters to ensure the stable operation of equipment and product quality.

Technical specifications(partial)

Model:BENTLY 3500/42M 176449-02

Number of channels:4 channels

Resolution:24 bits

Input type:eddy current sensor,velocity,acceleration,dual probe(velocity and displacement)

Output type:Configurable to activate alarm,trip shutdown sequence or trigger other necessary actions

Operating temperature range:-40°C to+85°C(some models may vary)
