Foxboro FBM230 Product Details

FBM230 Foxboro is a Field Device System Integrator(FDSI)module produced by Foxboro.The FBM230 Field Device System Integrator module provides a serial interface between single-port field I/O devices and the EcoStruxure™Foxboro™DCS system.It allows a single FBM230 to flexibly connect multiple similar but not identical devices to meet the various needs in the field of industrial automation.

Main Features

Multi-port configuration:The FBM230 has four ports,each of which can be individually configured in software as RS232,RS422 or RS-485 communication interface standards.This flexibility enables the FBM230 to connect to many different types of devices.

Extensive connectivity:Each FBM230 can communicate with up to 64 RS-485 or 4 directly connected RS-232 or RS-422 devices.In addition,up to 2,000 distributed control interfaces(DCIs)can be connected to read or write data from the Foxboro DCS control station connected to the FBM230.

Data Integration:The FBM230 is able to integrate field device data into the Foxboro DCS control database,facilitating centralized management and analysis of data.

Environmental Adaptability:The FBM230 is suitable for G3(harsh)environments and has high reliability and stability.

Software Driver:The FBM230 is a universal hardware module that can load different software drivers.These drivers configure the FBM to recognize the specific protocols used by field devices.Some of these software drivers are standard products,and other custom drivers can be developed based on specific needs.

Technical Specifications

Physical Wiring:Conforms to RS-232,RS422,or RS-485 standards of the Electronic Industries Association(EIA).

Transmission rate:supports multiple transmission rates such as 300,600,1200,2400,4800,9600,19200,38400,57600 and 115200 baud.

Protocol:supports 8-bit characters;odd,even or no parity,1 or 2 stop bits.

Power requirements:input voltage range is 24V DC+5%(-10%),power consumption is 7W(maximum),and heat dissipation is also 7W(maximum).

Application areas

The FBM230 Foxboro module has a wide range of applications in the field of industrial automation,including but not limited to

Process control systems:used to monitor and control various industrial processes,such as chemical plants,refineries,etc.

Power industry:used to monitor the status of the power grid,control power distribution and perform automated operations.

Manufacturing:integrated into the manufacturing automation system to control the production line,monitor the status of equipment and perform various tasks in the production process.

Equipment monitoring:used to monitor and report the operating status of the equipment,and perform necessary control operations.

Environmental Monitoring:Used to monitor environmental parameters such as temperature,humidity or pressure and control environmental conditions accordingly.
