BENTLY 3500/25 125792-01 Product Overview

BENTLY 3500/25 125792-01 is a high-performance frame interface module or digital control card module (the specific name may vary depending on the application scenario). The following is the detailed information of the product.

Product Overview

The BENTLY 3500/25 125792-01 module is compact and rugged, suitable for various harsh industrial environments. It provides multiple digital input and digital output channels for receiving external signals and controlling external devices. At the same time, the module also has alarm and diagnostic functions, which can monitor the status of input signals and trigger alarms when preset conditions are met.

Main functions

Digital input

Provides multiple digital input channels for receiving external signals.

The input channels can detect switch status, pulse counts or other digital signals.

Digital output

Equipped with digital output channels for controlling external devices or performing specific operations.

Through these output channels, switch signals can be sent or other digital control operations can be triggered.

Alarm and diagnostics

Equipped with alarm functions, it can monitor the status of input signals and trigger alarms when preset conditions are met.

Provides diagnostics to monitor the module’s own operating status and health.

Interfaces and Connectivity

Built-in network interface to interface directly to most gray code or binary SSI sensors.

Supports up to 12 SSI sensors on a single network connection.

Features simple programming capabilities without additional software.
