NI SCXI-1600 Product Introduction

SCXI-1600 is a high-performance data acquisition module produced by National Instruments(NI).The following is a detailed introduction to it.

Product Overview

The SCXI-1600 data acquisition module has up to 352 channels(there may be some restrictions in specific applications,such as 32 analog input channels)and is equipped with a 16-bit ADC(analog-to-digital converter).Its sampling rate is up to 200 kS/s(thousand samples per second),which can efficiently and accurately collect analog signals.This module can not only be used for data acquisition,but also as a full-function control and data module for SCXI digital I/O,switches,analog input and analog output modules.

Technical Specifications

Bus Type:SCXI

Operating System/Object:Supports Windows,Real-Time System,Linux,etc.

Measurement Type:Including current,temperature(such as using RTD sensor),thermocouple,voltage,etc.

Number of Channels:The number of analog input channels can reach 32(depending on the configuration and connection method)

Sampling Rate:Up to 200 kS/s

Bandwidth:10 kHz

Signal Conditioning:Supports 0-20 mA current input,low-pass filtering,etc.

System Timing Controller:Use National Instruments DAQ-STC to ensure the accuracy and stability of data acquisition

Product Features

High-Performance Data Acquisition:With high sampling rate and multi-channel design,SCXI-1600 can meet various high-precision data acquisition needs.

Full-Function Control:In addition to data acquisition,this module can also be used for full-function control of SCXI system,including digital I/O,switches,analog input and output,etc.

Ease of Use:SCXI-1600 supports plug-and-play.After being installed in the SCXI chassis,it can easily provide clock,calibration and external digital trigger connections for other SCXI modules.In addition,its front panel is equipped with LED indicators for monitoring the status of the chassis’V+and V-rails and the activity and readiness of the data acquisition module.

Wide signal compatibility:Able to receive analog signals from other modules and digitize,amplify and transmit them through the USB port.Compatible with a variety of signal types,such as RTD,thermocouple,strain gauge,current source and voltage,etc.

Powerful system timing controller:Use DAQ-STC as the system timing controller to ensure the accuracy and stability of data acquisition.

Application fields

SCXI-1600 data acquisition modules are widely used in various fields that require high-precision data acquisition and processing,such as industrial automation,environmental monitoring,scientific research experiments,etc.Its high sampling rate,multi-channel and ease of use make it an indispensable data acquisition tool for engineers and technicians.
