GE DS200DC Product Details

GE’s DS200DC series contains multiple circuit board assemblies and power modules that are commonly used in industrial automation and control systems.The following is a detailed introduction to some specific models in the GE DS200DC series.

DS200DCFBG1BJB circuit board assembly

Product Overview

DS200DCFBG1BJB is a circuit board assembly manufactured by General Electric and is part of the Mark V Speedtronic system.

This assembly is used to provide control-level power to drives and cabinet fans.

Application scenarios

DS200DCFBG1BJB is suitable for EX2000 applications and DC2000,FC2000,GF2000,ME2000,CB2000 and AC2000 IGBT drive applications.

The Mark V series has specific applications in the control and management systems of steam,wind and gas turbine automatic drive components.

Component Features

The DS200DCFBG1BJB is a large rectangular circuit board with a large number of components mounted on the surface,including seven 4-position DIP switch devices and 12 configurable jumpers.

The board features a neon light to indicate a blown fuse in the 115 VAC line,and two LED indicators to indicate blown fuses in the+24 VDC line and the-24 VDC line.

The component contains a variety of integrated circuits,such as voltage and current feedback VCO circuits,motor voltage attenuation circuits,AC line magnetic and zero-crossing circuits,contactor drive circuits,field/armature SCR ignition circuits,etc.

DS200DCFBG1BLC Power Supply Module

Product Overview

DS200DCFBG1BLC is a power supply board designed by General Electric for the Mark V series optional and replacement board.

This power supply board is cross-compatible with many GE brand exciters and drivers.

Application scenarios

Drivers of DC2000,AC2000,CB2000,ME2000 and FC2000 can all accept this power supply board.

This power board provides system control-level power to the drive it is installed on and powers the chassis fan.

Technical Specifications

The source AC input is rated at 38 to 115 VAC.

The frequency range is 0 to 500 kHz(depending on the strength of the input voltage).

Contains many complex circuit systems designed to power most drives,such as AC and DC monitoring circuits,control-level power circuits,motor excitation power circuits,and drive circuits.

Other DS200DC Series Components

In addition to the two specific models mentioned above,GE’s DS200DC series also includes other circuit board components and power modules,such as the DS200DCVAG1A DC power instrument controller,etc.These components are also generally highly reliable and performant,and are suitable for a variety of industrial automation and control system applications.
