ABB 5SHX1960L0004 Product Overview

ABB 5SHX1960L0004 thyristor IGCT card is a component used to control medium and high voltage power electronic devices.IGCT is a power electronic switching device that combines the characteristics of thyristor and insulated gate bipolar transistor(IGBT).It has both the high current handling capability of thyristor and the fast switching capability of IGBT.

Main Features

High power handling capability:The card is designed to handle high-power power electronic devices,capable of controlling high current and high voltage,and is suitable for a variety of high-power application scenarios.

Fast switching:IGCT has a fast switching speed,enabling fast power control,and is suitable for applications that require fast response.

High efficiency:The high efficiency of IGCT minimizes energy loss and improves the efficiency of the entire system.

High reliability:As a well-known electrical and automation solution provider,ABB’s products enjoy a high reliability reputation in industrial applications.The 5SHX1960L0004 card undergoes strict quality control and testing to ensure stable operation in various industrial environments.

Easy to integrate:The card adopts standard interface and modular design,which is easy to integrate with other ABB products or third-party devices,simplifying the system integration process.

Advanced control function:The 5SHX1960L0004 card is equipped with advanced control algorithms and protection functions to achieve precise control of power electronic equipment,and provides overcurrent,overvoltage and other protection functions to ensure the safe operation of the equipment.

Flexible configuration:The card supports a variety of configuration options to meet the needs of different applications,such as current and voltage range,switching frequency,etc.

Technical parameters

Rated voltage:3300V AC

Rated current:1900A

Peak forward current:3000A

On-state voltage drop:2.5V

Gate trigger current:0.5A

Operating temperature:-40°C to+85°C

Storage temperature:-40°C to+125°C

Dimensions:335mm x 250mm x 120mm

Application areas

ABB 5SHX1960L0004 thyristor IGCT card is widely used in the following fields

Power electronic systems:such as converters,inverters and DC-DC converters,used to adjust the voltage and current of power systems.

Power transmission and distribution:used to improve the efficiency and stability of power systems.

AC motor control:in large motor and drive systems,used to control the start and stop and speed regulation of AC motors.

Electrical control cabinet:integrated in the electrical control cabinet to provide precise control of power electronic equipment.

Renewable energy systems:used to control and regulate the conversion and transmission of electricity in wind and solar power generation systems.

Power quality regulation:used in power system quality regulation devices to maintain power quality and reduce harmonics.

Industrial automation:used to control high-power equipment such as furnaces and compressors.

Medical equipment:used for power control and regulation
