ABB P8295 Relay Module Detailed Technical Overview

The P8295 relay module is a powerful industrial grade relay control device widely used in automation control systems for driving and controlling high load equipment or for signal isolation. The following are the main features, technical specifications, and application scenarios of this module:

Product Features

High reliability design

Using industrial grade components with long lifespan and high reliability, suitable for harsh industrial environments.

Multi channel control

Provide multiple independent relay channels to control multiple devices simultaneously, with strong flexibility.

Strong electrical isolation

Having high voltage isolation capability, ensuring safe isolation between the control end and the load end, and protecting the control system.

Modular structure

Modular design facilitates installation, maintenance, and expansion, and can be quickly integrated into various systems.

Multiple contact forms

Supports normally open (NO) and normally closed (NC) contacts to meet different control requirements.

LED status indication

Each relay channel is equipped with LED indicator lights, which intuitively display the working status and facilitate troubleshooting.

technical specifications

Parameter specifications

Relay channel number: 8 channels, 16 channels (optional according to different models)

Maximum contact capacity 10A @ 250V AC or 30V DC

Control voltage 5V, 12V, 24V DC (optional according to different models)

Insulation withstand voltage ≥ 1500V AC

Response time ≤ 10ms

Working temperature range -20 ° C to 70 ° C

Installation method: DIN rail installation or screw installation

Modular and compact design, easy to integrate
