Honeywell CC-PCNT05 Analog Input Modules

The Honeywell CC-PCNT05 is a high-performance Analog Input Module designed for use in Honeywell’s Experion Process Knowledge System (PKS) and C300 controller platform. It provides reliable and accurate analog signal acquisition from field instruments, supporting a variety of input types such as 4–20 mA and 0–10 VDC. With advanced diagnostics, flexible configuration, and seamless system integration, the CC-PCNT05 enhances process visibility and control for mission-critical applications.

Key Features

• Supports multiple analog input types (current and voltage)

• High channel density for efficient I/O management

• Advanced self-diagnostics and fault detection

• Fully compatible with Honeywell Experion PKS and C300 systems

• Hot-swappable design for reduced downtime

• Configurable input ranges per channel

• Enhanced accuracy and stability

• DIN rail mountable form factor

Technical Specifications

Industry Applications

• Oil and Gas Process Control

• Chemical and Petrochemical Plants

• Power Generation and Utilities

• Water and Wastewater Management

• Food and Beverage Processing

• Pharmaceutical and Life Sciences

• Pulp and Paper Manufacturing

• Mining and Metals Automation

Product Advantages

• Flexible Signal Handling: Supports both current and voltage inputs for diverse process needs

• High Accuracy: Delivers precise signal acquisition across varying input ranges

• Hot-Swappable: Enables replacement without interrupting system operation

• Advanced Diagnostics: Provides real-time input monitoring and fault detection

• Space Efficient: Compact DIN rail mounting with 16 input channels

• System Integration: Seamlessly connects with Experion PKS and C300 platforms

• Long-Term Stability: Maintains performance across wide temperature ranges

• Simplified Maintenance: Status LEDs and auto-configuration reduce manual intervention

Frequently Asked Questions (FAQ)

1. What types of analog signals can the CC-PCNT05 accept?

It accepts 4–20 mA and 0–10 VDC signals, configurable per channel.

2. How many channels does this module have?

It provides 16 analog input channels.

3. Is the module hot-swappable?

Yes, it can be replaced without shutting down the system.

4. What is the resolution of input signals?

The input resolution is 16-bit.

5. What diagnostic features does it include?

It includes open circuit detection and signal range monitoring.

6. Is it compatible with the Experion PKS system?

Yes, it fully integrates with Experion PKS and C300 controllers.

7. What are the module’s physical dimensions?

Dimensions are 120mm x 90mm x 35 mm.

8. What certifications does it carry?

CE, UL, CSA, RoHS, and ATEX certified.

9. What is the power supply requirement?

It operates on a nominal 24 VDC power supply.

10. Can input channels be configured individually?

Yes, each channel can be independently configured for signal type and range.
