The Honeywell MU-TAOX12 51304335-100 Analog Output Terminal Assembly is a high-performance terminal module designed to facilitate the integration of Honeywell’s TotalPlant Solution (TPS) and PlantScape Distributed Control Systems (DCS). This module is designed for managing analog output signals from a central control system to field devices, ensuring seamless communication for real-time process control in industrial environments.

The MU-TAOX12 is engineered to provide precise control and signal conditioning, which is essential for industries such as oil & gas, chemical, power generation, and manufacturing. It can support up to 12 analog output channels, making it ideal for large-scale applications that require accurate signal processing and output delivery to a wide range of field devices.

Key Features

• 12 Analog Output Channels: Supports up to 12 analog outputs, providing flexibility for complex control systems

• Precision Control: Ensures accurate and reliable output signal transmission to connected field devices

• Seamless Integration: Fully integrates with Honeywell’s TPS and PlantScape systems, providing smooth operation across platforms

• Flexible Configuration: Configurable to meet specific system requirements and varying application needs

• High-Speed Performance: Ensures quick response times for real-time control and monitoring applications

• Robust and Reliable: Built to withstand harsh industrial environments, ensuring continuous, stable performance

• Space-Efficient: Compact design ideal for installation in Honeywell I/O racks

• LED Diagnostics: Provides real-time feedback on operational status and system health

Technical Specifications

Industry Applications

• Oil & Gas – Control of valves, actuators, and other field devices used in production and processing

• Power Generation – Output to control turbines, generators, and auxiliary equipment

• Chemical & Petrochemical – Automation of reactors, mixers, and chemical dosing systems

• Water & Wastewater – Control of pumps, filtration, and treatment systems

• Manufacturing – Automation of production lines, CNC machines, and robotics

• Pharmaceuticals – Output for precise control of batch processes and laboratory instruments

Advantages

• High Channel Density: Supports up to 12 analog output channels, offering flexibility in large control systems

• Precision Control: Built-in signal conditioning ensures that output signals are accurate and stable, crucial for process control

• Compatibility: Fully integrates with Honeywell’s TPS and PlantScape systems, ensuring easy configuration and operation within the broader system

• Industrial Durability: Designed to operate in harsh industrial conditions, ensuring long-term reliability and minimal maintenance

• Compact Design: The space-efficient design fits seamlessly into Honeywell I/O racks, saving space while maintaining performance

• Real-time Performance: Ensures fast and efficient data transmission for real-time control and monitoring

• LED Diagnostics: Provides quick visual feedback on the status of the module for easier troubleshooting

• Flexible Signal Output: Supports different signal types such as 4-20 mA or 0-10 V, making it adaptable to various applications

Frequently Asked Questions (FAQ)

1. How many analog output channels does the MU-TAOX12 support?

   It supports up to 12 analog output channels.

2. What types of analog signals can the MU-TAOX12 output?

   It supports 4-20 mA or 0-10 V output signals, depending on configuration.

3. Is this module compatible with Honeywell’s TPS and PlantScape systems?

   Yes, it is fully compatible and integrates seamlessly with Honeywell’s TPS and PlantScape DCS systems.

4. What is the operating temperature range for the MU-TAOX12?

   The module operates between 0°C and +60°C.

5. Can the MU-TAOX12 be used in harsh industrial environments?

   Yes, it is designed to withstand harsh industrial environments, ensuring long-term reliability.

6. What is the physical size of the MU-TAOX12?

   The module has approximate dimensions of 264 mm x 32 mm x 127 mm.

7. How does the module communicate with other Honeywell systems?

   It communicates via Honeywell’s I/O system interface, integrating seamlessly with the broader control system.

8. Can the MU-TAOX12 be easily maintained?

   Yes, it includes LED diagnostic indicators for real-time feedback, which simplifies maintenance and troubleshooting.

9. What is the maximum number of devices the MU-TAOX12 can control?

   The module can control up to 12 field devices simultaneously, depending on the configuration.

10. What certifications does the MU-TAOX12 have?

    The module is CE, UL, and CSA certified, ensuring compliance with industry safety and performance standards.
