The GE Fanuc IC694MDL645A RX3i Input Module is a high-density discrete input module designed for use with GE Fanuc PACSystems RX3i programmable automation controllers (PACs). This module provides reliable 120 VAC input signal detection and is optimized for industrial control systems that require accurate monitoring of field device status, including switches, sensors, and other discrete devices.

With a space-efficient 32-point design, the IC694MDL645A enhances system flexibility and reduces panel space requirements. Its robust construction, electrical isolation, and diagnostic features make it ideal for applications where high reliability and ease of integration are essential.

Key Features

• 32 Discrete Input Points: High-density module for space-saving installation

• AC Voltage Input: Accepts 120 VAC signals for monitoring field devices

• Group Isolation: Inputs divided into isolated groups for enhanced system protection

• LED Status Indicators: Individual point status LEDs simplify troubleshooting

• High Reliability: Designed for continuous operation in industrial environments

• PACSystems RX3i Compatibility: Seamless integration with GE Fanuc RX3i controllers and systems

• DIN Rail or Panel Mounting: Flexible installation options for various control cabinet layouts

• Industry-Standard Compliance: CE, UL, and CSA certifications for global use

Technical Specifications

Industry Applications

The IC694MDL645A RX3i Input Module is ideal for applications where reliable discrete input monitoring is essential:

• Factory Automation: Monitoring switches, sensors, and interlocks on assembly lines

• Power Generation: Field device status monitoring in turbine and substation control

• Water and Wastewater Treatment: Remote signal acquisition for pumps, valves, and alarms

• Oil & Gas: Safe input detection in compressor stations and refineries

• Building Automation: Monitoring alarms, doors, and safety interlocks

• Transportation Systems: Field signal acquisition for railways, tunnels, and airports

Product Advantages

• High-Density Input Design: 32 input points reduce rack space requirements

• AC Input Flexibility: Supports standard 120 VAC field devices

• Robust Electrical Isolation: Enhances system protection and reduces noise interference

• Clear Visual Diagnostics: Individual point LEDs simplify maintenance and fault detection

• System Compatibility: Fully integrates with GE Fanuc PACSystems RX3i controllers

• Durable Construction: Suitable for harsh industrial environments

• Fast Response Time: Ensures real-time input status updates for reliable control

• Flexible Installation: Supports both DIN rail and panel-mounted configurations

• Global Standards Compliance: Certified for use in international industrial systems

• Reduced Downtime: Simplified troubleshooting contributes to increased system uptime

Frequently Asked Questions (FAQ)

1. What does the IC694MDL645A module do?

   It monitors the status of discrete field devices by detecting 120 VAC input signals.

2. How many input points are provided?

   The module offers 32 discrete input channels.

3. What input voltage does the module support?

   It accepts nominal 120 VAC signals within 85 to 132 VAC range.

4. Does the module provide isolation between inputs?

   Yes, there are two groups of 16 inputs with isolation between groups and from system logic.

5. Are diagnostic indicators included?

   Yes, each input channel has a corresponding LED status indicator.

6. What type of systems is this module compatible with?

   It is designed for GE Fanuc PACSystems RX3i automation platforms.

7. Can the module be mounted on DIN rails?

   Yes, it supports both DIN rail and direct panel mounting.

8. What is the operating temperature range?

   It operates from 0°C to +60°C, suitable for industrial environments.

9. Does the module comply with international standards?

   Yes, it is CE, UL, and CSA certified.

10. Where is this module commonly used?

    Industries include manufacturing, power generation, oil & gas, infrastructure, and water treatment.
