The Honeywell FC-TSDO-1624 is a highly reliable and robust safe digital output module designed for safety-critical industrial applications. This module provides 16 channels of digital output, ensuring dependable and fail-safe control signals in safety instrumented systems (SIS).

Designed in accordance with stringent functional safety standards such as IEC 61508, the FC-TSDO-1624 excels in delivering fast and accurate digital switching outputs with a focus on minimizing downtime and improving process safety. Its compact size and efficient design make it ideal for integration into Honeywell’s safety management platforms, offering enhanced operational control in hazardous environments.

The module’s robust construction supports long-term durability even in challenging industrial conditions, including oil and gas, chemical processing, and power generation sectors.

Technical Specifications

Applications

The Honeywell FC-TSDO-1624 digital output module is engineered for use in safety-critical process control systems where safe and precise digital outputs are essential. Typical applications include:

• Oil and Gas Processing: Controlling emergency shutdown valves, safety interlocks, and alarms to maintain operational safety.

• Chemical Industry: Managing safety instrumented functions that require reliable digital output signals for shutoff valves and actuators.

• Power Generation: Providing fail-safe digital control for turbine shutdown and safety trip systems.

• Pharmaceutical Manufacturing: Ensuring safe and compliant operation of critical process controls through secure digital outputs.

• Water Treatment Plants: Safe management of pump controls and valve actuators in hazardous locations.

• Industrial Automation: Integration in complex safety systems requiring multiple digital outputs with high integrity.

Advantages

• High Safety Integrity: Certified to SIL 3 standards, ensuring maximum safety in critical environments.

• Compact and Lightweight: With dimensions of only 60 × 70 × 54 mm and weighing 0.36 kg, it fits well into space-limited control cabinets.

• Flexible Output Configuration: Supports relay or transistor outputs to meet diverse application needs.

• Robust Isolation: Provides excellent channel-to-channel and channel-to-system isolation to reduce interference and enhance reliability.

• Fast Response Time: Less than 10 ms switching time for quick and accurate safety responses.

• Wide Operating Range: Capable of functioning reliably in harsh temperature and humidity conditions.

• Easy Integration: Designed for seamless compatibility with Honeywell safety control systems.

Frequently Asked Questions (FAQ)

Q1: How many output channels does the FC-TSDO-1624 have?

A1: It provides 16 digital output channels.

Q2: What types of outputs are supported by this module?

A2: The module supports relay contacts or transistor outputs depending on configuration.

Q3: What is the maximum current per output channel?

A3: Each channel can handle up to 500 mA.

Q4: Is this module certified for SIL 3 safety applications?

A4: Yes, it is certified to meet SIL 3 standards.

Q5: What are the physical dimensions of the FC-TSDO-1624?

A5: The module measures 60 × 70 × 54 mm.

Q6: How much does the module weigh?

A6: The weight is approximately 0.36 kg.

Q7: What is the operating temperature range for this module?

A7: It operates between -20°C and +60°C.

Q8: Can the module be mounted on a DIN rail?

A8: Yes, it supports both DIN rail and panel mounting.

Q9: What is the typical response time for digital output switching?

A9: The response time is less than 10 milliseconds.

Q10: Is the FC-TSDO-1624 compatible with Honeywell’s safety management systems?

A10: Yes, it integrates seamlessly with Honeywell safety control platforms.
