The GE IS200TBAIH1C Analog Input Terminal Board is a precision-engineered interface board for accurately acquiring and conditioning analog signals in GE Mark VI and Mark VIe steam turbine control systems. It securely connects field instruments such as temperature transmitters, pressure sensors, and vibration probes to the turbine control hardware, ensuring reliable transmission of critical analog process data to the controller.

The IS200TBAIH1C utilizes low-noise circuitry, high signal fidelity, and robust electrical isolation to maintain accurate measurements even in harsh industrial environments. Supporting multiple isolated analog channels, the board is optimized for high-performance monitoring in mission-critical applications. Its rugged design, built to GE quality standards, makes it a key component for power generation, oil and gas, and other heavy industries where process accuracy and system reliability are paramount.

Product Specifications

Applications

• Turbine Control Systems: Acquires critical analog inputs for GE Mark VI and Mark VIe gas and steam turbine controllers.

• Process Automation: Integrates field instrumentation such as transmitters and sensors with control hardware.

• Power Generation Facilities: Enables real-time monitoring of vibration, temperature, and pressure signals to ensure efficient turbine operation.

• Oil & Gas Sector: Provides accurate analog data for compressor stations, refinery systems, and pipeline control.

• Industrial Manufacturing: Ensures reliable analog signal acquisition for process optimization and automation.

• Predictive Maintenance: Supplies precise data to enable early fault detection and equipment health monitoring.

Product Advantages

• High Accuracy: ±0.1% full-scale accuracy ensures reliable and precise analog data acquisition.

• Low-Noise Design: Advanced filtering and shielding minimize interference, delivering clean input signals.

• Robust Electrical Isolation: Protects the control system against surges and cross-channel noise.

• Fully Compatible with GE Systems: Optimized for seamless integration with Mark VI and Mark VIe architectures.

• Industrial Durability: Designed for continuous operation in demanding temperature and humidity conditions.

• Versatile Signal Support: Handles both current (4-20 mA) and voltage (0-10 VDC) analog inputs.

• Easy Installation: Terminal board format allows quick mounting and wiring inside control cabinets.

FAQ

1. What is the main function of the GE IS200TBAIH1C board?

   It serves as an analog input interface for GE Mark VI and Mark VIe turbine control systems.

2. What types of analog inputs does the IS200TBAIH1C support?

   It supports both 4-20 mA current signals and 0-10 VDC voltage signals.

3. Does the board provide electrical isolation?

   Yes, it provides galvanic isolation between input channels and the control system.

4. Can the IS200TBAIH1C handle multiple analog inputs simultaneously?

   Yes, it supports multiple isolated channels for comprehensive signal acquisition.

5. Is this board compatible with gas and steam turbines?

   Yes, it is suitable for control applications in gas and steam turbines.

6. Does the IS200TBAIH1C have built-in signal conditioning?

   Yes, it includes low-noise amplification and filtering for accurate data transmission.

7. What is the accuracy rating of this terminal block?

   It provides ±0.1% full-scale accuracy to ensure precise analog signal acquisition.

8. Can it be used in high EMI industrial environments?

   Yes, it is shielded and isolated for reliable operation in noisy environments.

9. What power supply does the IS200TBAIH1C require?

   It is powered by the nominal 24 VDC supply provided by the turbine control cabinet.

10. Does this motherboard meet industrial safety standards?

    Yes, it meets CE, UL, RoHS and IEC compliance requirements.
