Designed with ABB’s emphasis on durability and industrial performance, the SDCS-MP-1 offers a dependable foundation for heavy-duty drive operations, from steel mills to chemical plants.

Product Advantages

• High Compatibility: Fully compatible with ABB DCS400 and DCS500 drives, ensuring seamless integration.

• Stable Performance: Delivers stable and efficient processing of drive control signals, minimizing operational interruptions.

• Modular Design: Facilitates easy maintenance and replacement, reducing overall system downtime.

• Industrial Grade Reliability: Designed for long life in industrial applications, including high temperatures and electrical noise environments.

• Efficient Communication: Supports fast data exchange with other modules via fiber optic links and serial communication ports.

• Extended Diagnostic Capabilities: Includes built-in diagnostics for system status, fault tracking, and performance monitoring.

Technical Specifications

Product Applications

• Metallurgical Industry: Control of DC motors in rolling mills and metal processing lines.

• Pulp and Paper: Ensures precise torque and speed control in paper machines.

• Oil & Gas: Used in pump drives and drilling control systems.

• Chemical Processing: Reliable speed control in mixers and chemical feed systems.

• Marine Industry: DC propulsion and winch systems.

• General Manufacturing: For all motor-driven processes requiring precision control and system monitoring.

Installation Instructions

1. Power Down the System: Ensure all power sources to the converter are disconnected before installation.

2. Access the Drive Cabinet: Open the ABB DCS drive unit and locate the control board slot.

3. Insert the SDCS-MP-1: Slide the module carefully into the designated position, ensuring alignment with the guide rails.

4. Secure the Module: Use screws or latching clips as applicable to secure the module firmly.

5. Connect Fiber and Communication Cables: Attach any fiber optic or serial communication cables according to ABB connection diagrams.

6. Run Initial Diagnostic Check: Once powered, monitor the diagnostic LEDs and verify module recognition via the drive software.

Frequently Asked Questions (FAQ)

Q1: What does the SDCS-MP-1 module control in the ABB DCS drive?

A1: It serves as the main processor that handles logic, control algorithms, and communication with peripheral modules.

Q2: Can I use SDCS-MP-1 in DCS600 systems?

A2: No, the SDCS-MP-1 is designed specifically for the DCS400 and DCS500 series.

Q3: How do I know if the SDCS-MP-1 module is faulty?

A3: Diagnostic LEDs on the module indicate fault conditions. Additionally, error codes will appear on the drive interface.

Q4: Is firmware upgrade possible on this module?

A4: No, this module does not support field firmware updates and must be replaced if a firmware revision is required.

Q5: Does the module require external power supply?

A5: No, the module is powered internally by the drive’s control power.

Q6: How do I clean the module if it’s dusty?

A6: Use dry compressed air or a soft brush. Avoid using liquids or solvents.

Q7: Is the SDCS-MP-1 hot-swappable?

A7: No, always power down the system before removing or installing the module.

Q8: What type of cable should be used for the fiber optic connection?

A8: Use ABB-specified industrial-grade fiber cables with compatible connectors.

Q9: Can I use the SDCS-MP-1 in outdoor applications?

A9: No, it’s designed for enclosed environments within control cabinets.

Q10: How long is the typical lifespan of the SDCS-MP-1?

A10: Under standard conditions, it can operate reliably for over 5 years.
