GE Fanuc IC693ACC300 Input Simulator Module

The IC693ACC300 is an input simulator module designed for use with GE Fanuc’s Series 90-30 PLCs. This module allows for the simulation of up to 16 discrete input points, providing an effective solution for testing and troubleshooting PLC systems. The IC693ACC300 features 16 miniature toggle switches (A1-A8, B1-B8), each with corresponding green LEDs. These LEDs light up when the switches are in the “ON” position, offering clear visual feedback. It operates on DC voltage, with a voltage range of 18 to 30 Volts DC, and can be installed in either a 5-slot or 10-slot baseplate.

Technical Specifications

• Brand: GE Fanuc
• Series: Series 90-30
• Part Number: IC693ACC300
• Type: I/O module (Discrete DC voltage input simulator)
• Input Points: 8/16
• Power Source: DC (18 to 30 Volts DC)
• Switches: 16 two-position toggle switches (A1-A8, B1-B8) with green LEDs
• Operating Temperature: 0 to 55°C (32 to 131°F)
• Storage Temperature: -40 to 85°C (-40 to 185°F)
• Relative Humidity: 5 to 95% (non-condensing)
• Shock Resistance: 15 G at 11 milliseconds
• Vibration Resistance: 1 G at 9 to 150 Hertz
• Installation: Compatible with 5-slot or 10-slot baseplates (any I/O slot)
• Weight: 0.37 lbs
