The ABB SF810-FOC-IR-TL is a flame scanner used in industrial and utility boilers to monitor flame stability and quality. It ensures reliable detection of flames, helping optimize boiler performance and safety.

Technical Specifications

• Model: SF810-FOC-IR-TL
• Manufacturer: ABB
• Type: Flame Scanner
• Sensor Technology: Infrared (IR) solid-state sensor
• Spectral Response Peak: 920 nm
• Power Supply Voltage: Powered by Flame Analysis Unit FAU810
• Power Consumption: Max 300 mW / 600 mW (Dual Sensor)
• Air Source for Lens Cleaning: Clean ambient air
• Air Flow for Lens Cleaning: 400 l/min (14 SCFM)
• Minimum Cleaning Air Pressure: 300 mm H2O (12” W.C.) above max wind box pressure
• Maximum Fiber Optic Continuous Operating Temperature: 482°C (900°F)
• Housing Mounting Thread: 1” NPT male
• Cable Entry Thread: Quick release connector for IP66/67 or II 2GD Ex d IIC T6 hazardous areas
