GE Fanuc IC670MDL640B Discrete Input Module

The GE Fanuc IC670MDL640B is a versatile discrete input module within the GE Fanuc Field Control I/O module series. It provides 16 separate inputs that support both positive and negative logic. This module is suitable for various industrial applications, including machine control, process control, material handling, and robotics. It is designed to work with a 24 Volts DC system and has a wide input voltage range of 0 to 30 Volts DC, making it adaptable to different operational requirements.

Technical Specifications

• Input Channels: 16 discrete inputs
• Input Voltage Range: 0 to 30 Volts DC
• Nominal Input Signal: 24 VDC
• On-State Voltage:
  • Positive Logic: +15 to +30 Volts
  • Negative Logic: -15 to -30 Volts
• Off-State Voltage:
  • Positive Logic: 0 to +5 Volts
  • Negative Logic: 0 to -5 Volts
• On-State Current: 3.0 mA to 8 mA
• Off-State Current: 0 to -5 VDC
• Input Impedance: 3K ohms (typical)
• Input Response Time:
  • On/Off Transition: 6 ms (typical), 10 ms (maximum)
• Isolation Voltage:
  • Continuous: 250 Volts AC
  • For 1 minute: 1500 Volts AC
• Current Drawn from BIU Power Supply: 75 mA (typical), 83 mA (maximum)
• Weight: 0.44 lbs
