Manufactured with meticulous quality standards and advanced signal conditioning technology, the AIP423-S1 enables high-speed, noise-resistant, and accurate signal acquisition. It is designed to support standard 4–20 mA current loops and includes HART communication capability, allowing for seamless integration with smart field devices.

Technical Specifications

Applications

The AIP423-S1 analog input module is used across a wide range of industries that rely on accurate and stable analog signal acquisition. It is particularly valuable in:

• Petrochemical Plants: For monitoring pressure, flow, and level signals from transmitters in hazardous zones.

• Power Generation: For collecting temperature and steam flow data in turbine systems.

• Water & Wastewater Treatment: For real-time monitoring of pH, DO, turbidity, and other water quality indicators.

• Food & Beverage Processing: To ensure consistent quality control via sensor inputs across various processing stages.

• Pharmaceutical Manufacturing: For GMP-compliant process monitoring and integration with smart field devices.

• Mining & Metals: For rugged process environments where signal integrity is critical.

Product Advantages

• High Accuracy and Stability: Delivers precision data conversion, ensuring process control systems maintain optimal performance.

• Integrated HART Communication: Allows for easy integration with smart field instruments, improving diagnostics and configuration.

• Compact Design: Its slim profile conserves space in I/O racks while supporting high-density installation.

• Enhanced Reliability: Industrial-grade build quality, along with channel and bus isolation, minimizes signal interference and increases durability.

• Flexible Signal Handling: Compatible with both 2-wire and 4-wire field devices, enhancing system compatibility.

• Hot Swap Capability: Enables field replacement without shutting down the system, improving system availability.

• Advanced Diagnostics: In-built capabilities like open/short detection support predictive maintenance and faster troubleshooting.

• Wide Environmental Range: Reliable operation in challenging industrial environments with varied temperatures and humidity levels.

FAQs

Q1: What is the main function of the AIP423-S1 module?

A1: It acquires 4–20 mA analog signals from field transmitters and converts them into digital signals for use in Yokogawa’s control systems.

Q2: Does the AIP423-S1 support smart transmitters using the HART protocol?

A2: Yes, the module fully supports HART communication, allowing access to advanced transmitter diagnostics and configuration.

Q3: How many input channels are available on this module?

A3: The AIP423-S1 offers 16 input channels for current-based analog signals.

Q4: Can this module be hot-swapped during operation?

A4: Yes, it supports hot swapping, which allows for replacement without system downtime.

Q5: What kind of isolation does this module provide?

A5: The module provides both channel-to-channel and channel-to-bus isolation for improved signal integrity and safety.

Q6: What are the installation requirements for this module?

A6: It is designed to be mounted on a dedicated I/O base or terminal block within the Yokogawa DCS infrastructure.

Q7: What is the typical accuracy of the input signal?

A7: The AIP423-S1 provides an accuracy of ±0.1% of the full signal span.

Q8: Is this module suitable for use in hazardous areas?

A8: Yes, with appropriate barriers or when installed in certified systems, it is suitable for hazardous environments. It holds ATEX, IECEx, and FM certifications.

Q9: What is the lifespan or typical MTBF of this module?

A9: Yokogawa designs these modules with long operational life in mind, often exceeding 10 years with an MTBF above 250,000 hours.

Q10: What happens if a sensor wire becomes disconnected?

A10: The module has built-in diagnostic features to detect open circuits and generate alarms for immediate attention.
