The ABB CI869K01 3BSE049110R1 is a high-performance communication interface module designed to bridge communication between field devices and automation systems. As a core component of ABB’s comprehensive industrial control systems, this module is engineered to enable seamless integration with various industrial networks and protocols. It is designed for use in demanding environments, where reliability, efficiency, and stability are paramount.

This module supports Modbus, Profibus, and other industrial protocols, making it highly versatile for a range of automation and process control applications. The CI869K01 module is easy to integrate into both existing and new systems, making it an ideal solution for applications that require robust, real-time communication.

Product Parameters

Product Applications

The CI869K01 3BSE049110R1 interface module is designed to be used in various industrial automation applications where reliable communication between different devices is crucial. It is ideal for distributed control systems (DCS), supervisory control and data acquisition (SCADA) systems, and other industrial control networks. Common applications include:

• Process Automation: The module facilitates the integration of process instruments like flowmeters, pressure transmitters, and level sensors into a control system.

• Factory Automation: It allows for smooth communication between PLCs, robotic systems, and peripheral equipment on the production floor.

• Energy Management: The module enables integration with energy metering systems, ensuring accurate data collection and control for optimizing energy consumption.

• Building Automation: It integrates heating, ventilation, and air conditioning (HVAC) systems into centralized control units for optimal energy management.

• Industrial Data Acquisition: The CI869K01 is well-suited for applications requiring precise data collection from field sensors and transmission to central databases for further analysis.

• Substation Automation: It is used in electrical substations for communication between protection relays, control units, and monitoring systems.

Product Advantages

1. Multi-Protocol Support: Supports multiple industrial communication protocols, including Modbus RTU, Profibus DP, and Ethernet, ensuring seamless integration with a wide variety of devices.

2. Compact Design: With dimensions of 127.5 × 186 × 59 mm and a weight of 0.7 kg, the module is compact and easy to fit into control cabinets with limited space.

3. Reliable Performance: Built for industrial environments, it ensures stable communication even in high-noise and harsh conditions.

4. Energy Efficient: With a low current consumption of approximately 300 mA, the module operates efficiently, minimizing energy costs in industrial installations.

5. High Temperature Tolerance: Operating in temperatures from 0°C to +60°C and withstanding storage temperatures between -25°C and +70°C, the module is suitable for various environmental conditions.

6. Flexible Mounting: The DIN rail mounting ensures easy and secure installation in industrial control panels.

7. Durability: The module features a robust design, ensuring long-term performance and reducing the need for frequent replacements.

8. Wide Compatibility: It is compatible with a variety of ABB’s industrial control and automation systems, ensuring smooth communication with other ABB devices.

9. Simplified Integration: Its easy integration with legacy systems and modern infrastructures reduces installation time and costs.

10. Scalable Solution: The CI869K01 module supports scalable system architectures, making it ideal for both small-scale and large-scale industrial systems.

FAQ

1. What is the main function of the ABB CI869K01 interface module?

   • The module is designed to enable communication between field devices and automation systems, supporting protocols like Modbus RTU, Profibus DP, and Ethernet.

2. What communication interfaces does the CI869K01 support?

   • The module supports both RS-232 and RS-485 interfaces, offering flexibility for various system configurations.

3. What industrial protocols are supported by the CI869K01?

   • The CI869K01 supports Modbus RTU, Profibus DP, and Ethernet, allowing it to connect with a wide range of industrial devices.

4. Can the CI869K01 module be used in outdoor environments?

   • The module is designed for indoor use with an operating temperature range of 0°C to +60°C and is intended to be installed in protected environments such as control panels.

5. How is the CI869K01 powered?

   • The module operates on a 24 V DC power supply with a tolerance of ±20%.

6. What is the weight of the CI869K01 module?

   • The module weighs 0.7 kg, making it lightweight and easy to install.

7. What is the mounting method for the CI869K01?

   • The module is mounted on a DIN rail, ensuring secure installation and ease of integration.

8. What is the protection rating of the CI869K01?

   • The module has an IP20 protection rating, which is standard for industrial applications where exposure to dust and water is minimal.

9. Can the CI869K01 interface with existing systems?

   • Yes, the CI869K01 can be integrated into both new and existing industrial systems, supporting legacy devices and modern technology.

10. What is the temperature range for the CI869K01 module?

    • The CI869K01 operates within a temperature range of 0°C to +60°C, making it suitable for a variety of industrial environments.
