GE Fanuc IC660EBD110 Genius I/O Module Electronic Assembly

The IC660EBD110 is an electronic assembly used in the Genius I/O system, designed by GE Fanuc, now part of Emerson Automation. It works with the IC660TBD110 terminal base to form the IC660BBD110 16-channel discrete input block, operating at 93-132 VAC. The module is discontinued but was once a key component for industrial control systems requiring robust and reliable input processing.

Technical Specifications

• Brand: GE Intelligent Platforms / GE Fanuc
• Series: Genius I/O
• Manufacturer: GE Fanuc / Emerson Automation
• Product Type: Electronic Assembly
• Product Description: Electronic assembly for Genius I/O module
• Compatible Module: IC660BBD110 (16 discrete input channels)
• Compatible Terminal Base: IC660TBD110
• Size: 8.83 x 3.50 x 3.94 inches
• Weight: 4 lbs

Electrical Specifications

• Nominal Input Voltage: 115 VAC
• Input Voltage Range: 93-132 VAC
• Input Current: 5 A
• Operating Voltage: 93-132 V AC
• Input to Ground Isolation: 1500 V
• Frequency Range: 47-63 Hz
• Required Power:
  • 8 mA block current
  • 200 mA circuit current
• Heat Dissipation: 28 W max (16 inputs ON at full current)

Environmental Conditions

• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 100°C
• Humidity: 5-95% non-condensing
• Vibration: 5-10 Hz, 2” or 5.088 displacement
