Yokogawa S9681DB-0 Digital Oscilloscope

The YOKOGAWA S9681DB-0 is a high-performance digital oscilloscope designed for demanding applications in electronics, telecommunications, and research and development.

Key Features

• High Bandwidth: The S9681DB supports up to 2 GHz bandwidth, enabling it to capture and analyze high-speed signals.
• Deep Memory: With a memory depth of up to 2 Mbytes, it captures long waveforms efficiently.
• Advanced Triggering: It includes advanced triggering capabilities to capture elusive events.
• Wide Measurement Range: Measure voltage, current, time, and frequency with ease.
• Intuitive Interface: The interface is user-friendly, making operation straightforward.

Technical Specifications

• Bandwidth: 2 GHz
• Memory Depth: 2 Mbytes
• Sample Rate: 5 GSa/s
• Number of Channels: 4
• Vertical Resolution: 10 bits
• Horizontal Resolution: 2.5 ns/div
• Time Base Range: 5 ns/div to 10 s/div
• Trigger Types: Edge, pulse width, delay, video, and more
• Measurement Functions: Voltage, current, time, frequency, and more

Applications

• Electronics Troubleshooting: Quickly diagnose and resolve issues.
• Telecommunications Testing: Ensure signal integrity and performance.
• Research and Development: Support advanced research and experimental setups.
• Education: Provide hands-on learning experiences.
• Industrial Automation: Monitor and control automated processes.
