ABB CI511-ETHCAT 1SAP220900R0001 S500 Interface Module

The ABB CI511-ETHCAT 1SAP220900R0001 is a high-quality communication interface module designed to integrate ABB’s S500 I/O systems into EtherCAT industrial Ethernet networks. EtherCAT (Ethernet for Control Automation Technology) is renowned for its real-time data transfer capabilities and efficient handling of automation tasks. This module acts as a gateway that enables seamless data exchange between the S500 I/O modules and EtherCAT controllers, providing robust connectivity for modern industrial automation systems.

Engineered to meet stringent industrial standards, the CI511-ETHCAT supports high-speed, deterministic communication which is critical for applications demanding precise control and synchronization. The compact size, combined with efficient power consumption and simple DIN rail mounting, makes it a practical solution for space-constrained control cabinets. Its enhanced diagnostic features assist in minimizing downtime by enabling quick identification of communication issues.

Product Specifications

Product Applications

The CI511-ETHCAT interface module is engineered for versatile applications requiring reliable and high-speed communication between ABB S500 I/O systems and EtherCAT networks. Typical applications include:

• Factory Automation: Facilitates synchronization and real-time control of machinery and production lines, improving efficiency and throughput.

• Process Automation: Suitable for chemical, pharmaceutical, and food & beverage industries where precise timing and control are essential.

• Robotics: Supports communication in robotics applications requiring low latency and high reliability.

• Packaging Industry: Enables coordinated control of packaging machinery to optimize speed and accuracy.

• Material Handling Systems: Provides reliable data exchange for conveyor systems, automated storage, and retrieval systems.

• Energy Sector: Used in power generation and distribution automation where robust, deterministic communication is needed.

Product Advantages

1. EtherCAT Protocol Support: Ensures real-time, deterministic communication, reducing cycle times and improving synchronization.

2. Compact Design: The module’s dimensions (62 x 76 x 67.5 mm) and lightweight build (0.138 kg) allow installation in space-limited environments.

3. Dual Ethernet Ports: Supports daisy-chaining for flexible network topology and simplified wiring.

4. Robust Diagnostics: Integrated diagnostic LEDs facilitate rapid troubleshooting and minimize system downtime.

5. Energy Efficient: Low power consumption (~1.1 W) promotes energy savings in large-scale systems.

6. Wide Operating Range: Operates reliably from -20°C to +60°C, suitable for various industrial environments.

7. Easy Installation: DIN rail mounting reduces installation time and effort.

8. High Compatibility: Fully compatible with ABB’s S500 I/O modules, enhancing system flexibility.

9. Industrial-Grade Build: Designed to withstand industrial environmental conditions with IP20 protection.

10. Improved Network Performance: The EtherCAT protocol’s speed and efficiency enhance overall control system responsiveness.

FAQs

1. Which communication protocol does the CI511-ETHCAT module use?

   It uses the EtherCAT industrial Ethernet protocol.

2. What is the operating voltage of the module?

   The module operates at 24 V DC.

3. What are the physical dimensions of this interface module?

   The dimensions are 62 x 76 x 67.5 mm.

4. How much does the CI511-ETHCAT weigh?

   It weighs 0.138 kg.

5. How many Ethernet ports are available on the module?

   The module has 2 EtherCAT Ethernet ports.

6. What is the operating temperature range?

   It operates between -20°C and +60°C.

7. What is the protection class rating?

   The protection rating is IP20.

8. Can the module be installed on a DIN rail?

   Yes, it is designed for DIN rail mounting.

9. What is the power consumption of the CI511-ETHCAT?

   It consumes approximately 1.1 W.

10. Is this module compatible with other ABB S500 I/O modules?

    Yes, it is fully compatible with the ABB S500 series.
