Honeywell CC-TAIN11 51306515-175 Analog Input Modules

This module ensures continuous data integrity, high fault tolerance, and rapid diagnostics, contributing to reduced downtime and improved operational efficiency.

Technical Specifications

Product Applications

The CC-TAIN11 is designed for a wide range of industrial automation and control applications where accurate and reliable analog input acquisition is critical. Key sectors and use cases include:

• Oil & Gas: For pressure, temperature, and flow signal acquisition from field transmitters.

• Petrochemical Plants: Real-time monitoring of batch processes and feedstock control.

• Power Generation: Analog input monitoring from turbines, transformers, and load systems.

• Water Treatment Facilities: pH, chlorine, and turbidity sensor integration.

• Pharmaceutical Manufacturing: Input collection from cleanroom instrumentation and sterilization systems.

• Food and Beverage: Process control of mixers, heaters, and filling systems.

• Pulp & Paper: Monitoring consistency, flow, and chemical dosing in real time.

Product Advantages

• High Precision Data Acquisition: Offers 16-bit resolution for accurate analog signal capture, ensuring process accuracy and reducing variability.

• Integrated Diagnostics: Built-in diagnostics simplify maintenance and enhance system reliability through proactive fault detection.

• Hot Swappable: Allows for module replacement without shutting down the system, minimizing process interruptions.

• Compact Design: Small form factor enables easy installation in space-constrained environments.

• Robust Isolation: Ensures protection from electrical noise and potential field faults, increasing operational lifespan.

• Firmware Upgrade Capability: Extend functionality and security with seamless firmware updates.

• Versatile Input Support: Supports both current and voltage analog signal types, enhancing field compatibility.

• Certified for Global Use: Meets international compliance standards including CE, UL, and FM, ensuring global deployability.

FAQs

Q1: What is the primary function of the CC-TAIN11 module?

A1: The CC-TAIN11 functions as a 16-channel analog input module for interfacing with field transmitters that provide current or voltage signals.

Q2: Can the CC-TAIN11 module be used in hazardous environments?

A2: Yes, it complies with global certifications such as FM and CSA, making it suitable for deployment in classified or hazardous zones.

Q3: Is the module hot-swappable?

A3: Yes, the CC-TAIN11 supports hot-swapping for easy maintenance and zero system downtime.

Q4: What type of analog signals does the module accept?

A4: It accepts standard 4–20 mA and 1–5 VDC analog inputs.

Q5: Does it support redundancy?

A5: Yes, it can be configured within redundant I/O chassis to ensure high availability.

Q6: How is the module configured?

A6: Configuration is done through Honeywell’s system software, such as Experion PKS configuration tools.

Q7: Can I use this module with other Honeywell I/O modules?

A7: Yes, it is fully compatible with other modules in the same I/O chassis, allowing for mixed module configurations.

Q8: What is the maximum cable length from field devices to the module?

A8: Cable length depends on signal type, but for 4–20 mA inputs, up to 600 meters is generally acceptable using shielded twisted-pair cables.

Q9: What tools are required for firmware updates?

A9: Firmware updates can be performed using Honeywell’s control system engineering tools with USB or Ethernet connectivity.

Q10: How do I replace a faulty CC-TAIN11 module?

A10: Simply remove the module from the chassis using the release latch, insert the replacement, and reconfigure it using system tools—no power cycling required.
