ABB ATMB-01C 68908574B Temperature Measuring Board

The ABB ATMB-01C 68908574B Temperature Measuring Board is engineered for precise temperature monitoring within ABB inverter drives. This module plays a critical role in safeguarding inverter components by continuously measuring internal temperatures, thereby preventing overheating and ensuring optimal performance. Its robust design and compatibility with ABB systems make it a reliable choice for industrial applications requiring accurate thermal management.

Product Specifications

Product Applications

The ABB ATMB-01C 68908574B is utilized in various industrial sectors where precise temperature monitoring is essential:

• Power Generation: Monitoring temperatures in turbines and generators to prevent overheating.

• Chemical Processing: Ensuring temperature stability in reactors and processing units.

• Oil and Gas: Managing temperatures in drilling equipment and pipelines.

• Manufacturing: Controlling thermal conditions in production machinery.

• HVAC Systems: Regulating temperatures in heating, ventilation, and air conditioning systems.

• Renewable Energy: Monitoring temperatures in solar inverters and wind turbine converters.

Product Advantages

1. High Precision Monitoring: Offers accurate temperature readings with a resolution of 0.1°C, ensuring reliable thermal management.

2. Robust Design: Built to withstand harsh industrial environments, providing durability and longevity.

3. Easy Integration: Seamlessly integrates with ABB inverter drives, simplifying installation and reducing setup time.

4. Multi-Channel Input: Supports multiple analog inputs and outputs, allowing for comprehensive temperature monitoring across various components.

5. Diagnostic Features: Equipped with LED indicators for real-time status monitoring and fault detection.

6. Protection Mechanisms: Includes over-voltage, short-circuit, and overload protection to safeguard both the module and connected equipment.

7. Compliance with Standards: Certified with CE, RoHS, and UL, meeting international safety and quality standards.

8. Compact Form Factor: Space-efficient design suitable for installations with limited space.

9. Versatile Communication: Supports Fieldbus and serial communication protocols for flexible system integration.

10. Wide Operating Range: Functions effectively across a broad temperature range, accommodating various industrial environments.

FAQ

1. Q: What is the primary function of the ATMB-01C 68908574B?

   A: It monitors internal temperatures within ABB inverter drives to prevent overheating and ensure optimal performance.

2. Q: How does the module connect to the inverter system?

   A: It utilizes a 2-wire, 4-terminal connection for accurate temperature sensing integration.

3. Q: What temperature range can the module accurately measure?

   A: It measures temperatures ranging from -40°C to +100°C.

4. Q: What is the resolution of the temperature measurements?

   A: The module provides high-resolution temperature readings with a precision of 0.1°C.

5. Q: How many input and output channels does the module support?

   A: It supports 8 analog input channels and 4 analog output channels.

6. Q: What types of signals are compatible with the input and output channels?

   A: The module supports 0-10V and 4-20mA signal types for both inputs and outputs.

7. Q: What are the protection features included in the module?

   A: It includes over-voltage, short-circuit, and overload protection mechanisms.

8. Q: What certifications does the module have?

   A: The module is certified with CE, RoHS, and UL standards.

9. Q: What is the recommended mounting method for the module?

   A: It is designed for DIN rail mounting.

10. Q: What communication protocols does the module support?

    A: It supports Fieldbus and serial communication protocols for system integration.
