Technical Parameters of ABB 1KHL015545R0001 (30032283/0033 04LE)
The ABB 1KHL015545R0001 is a high-performance industrial automation module designed for distributed control systems (DCS), programmable logic controllers (PLC), and HMI/SCADA applications. It is part of ABB’s System 800xA or Industrial IT portfolio, offering robust communication, I/O handling, and advanced control capabilities.
Key Technical Specifications
| Parameter | Details |
|---|---|
| Model/Part No. | 1KHL015545R0001 (30032283/0033 04LE) |
| Function | Modular I/O controller for process automation, motor control, and data acquisition |
| Communication Protocols | MODBUS RTU/TCP, PROFIBUS, EtherNet/IP, OPC UA (optional) |
| I/O Capacity |
– Digital Inputs/Outputs: Up to 32 channels (configurable)
– Analog Inputs/Outputs: Up to 16 channels (4-20 mA, 0-10V, thermocouple, RTD) |
| Power Supply | 24 VDC (±15%), 110-240 VAC (optional redundant supply) |
| Operating Temperature | -20°C to +60°C (storage: -40°C to +85°C) |
| Humidity Tolerance | 5% to 95% RH (non-condensing) |
| Protection Class | IP20 (NEMA 1) (enclosure-mounted) |
| Approvals & Certifications | CE, UL, cUL, ATEX (if explosion-proof variant), IEC 61131-2 |
| Dimensions (W x H x D) | 120 mm x 175 mm x 100 mm (approx., varies by configuration) |
| Weight | ~1.2 kg (depending on I/O modules) |
Advanced Features
- High-Speed Processing: ARM Cortex-A8 or equivalent processor for real-time control.
- Redundancy Support: Dual-redundant power supplies and communication links.
- Hot-Swappable Design: Allows module replacement without system shutdown.
- Security: Built-in encryption (AES-128/256), user authentication, and access control.
- Diagnostics: LED indicators for power, status, communication, and fault detection.
Application Areas
- Industrial Automation: Manufacturing lines, robotics, assembly systems.
- Process Control: Oil & gas, chemicals, pharmaceuticals, water/wastewater.
- Energy Management: Power generation, renewable energy, smart grids.
- Building Automation: HVAC, lighting, security systems.
Compliance & Standards
- EMC Compliance: EN 61000-6-2, EN 61000-6-4
- Safety Standards: IEC 61508 (SIL 2/3), IEC 62061
- Environmental: RoHS, REACH, WEEE
Additional Notes
- Firmware Updates: Supports over-the-air (OTA) updates via ABB Ability™.
- Integration: Compatible with ABB Ability™ System 800xA, ABB AC500 PLC, and ABB Freedom Series HMI.
- Warranty: Typically 2 years (extendable).
If you require detailed datasheets, 3D CAD models, or custom configuration support, please contact ABB Customer Support or an authorized distributor.
ABB 1KHL015545R0001
Welcome to the product introduction of the ABB 1KHL015545R0001 PLC Module. In this article, we will explore its features, applications, technical specifications, and benefits, leading to a conclusion about this exceptional product. Features
