Hima Z7138/3330/C6/P2 Cable Plug

The HIMA Z7138/3330/C6/P2 Cable Plug is a precision-engineered 6-pole industrial connector, designed specifically for high-reliability signal and power connections in critical safety applications. Built to meet stringent industrial standards, this plug forms a vital part of distributed control and safety instrumented systems (SIS), particularly in hazardous or mission-critical environments.

With a rugged nickel-plated housing and high-performance EMC shielding, the Z7138/3330/C6/P2 ensures a secure, interference-free interface between field devices and automation controllers. Its modularity, mechanical strength, and IP-rated protection make it suitable for both cabinet-mounted and field-level installations.

This version (C6/P2) includes a 6-contact configuration with P2-style coding for alignment and protection, optimized for integration in HIMA HIMax and HIMatrix systems, while maintaining compatibility with other industrial automation solutions.

Product Specifications

Product Applications

• Safety Instrumented Systems (SIS): Ensures fail-safe wiring in ESD, F&G, and BMS systems.

• Industrial Control Cabinets: Used for secure signal interfacing between modules and field wiring.

• Chemical & Petrochemical Plants: Offers corrosion-resistant connections for hazardous area I/O.

• Power Generation Facilities: Provides robust connections for turbine and relay control signals.

• Transportation Infrastructure: Interfaces with safety logic systems in rail and airport automation.

• OEM Automation Panels: Integrates into modular safety and control devices with minimal footprint.

Product Advantages

• High Mechanical Integrity: Withstands physical stress and frequent mating cycles without degradation.

• Reliable Signal Isolation: High insulation resistance ensures safe, noise-free signal transmission.

• EMC-Resistant Design: 360° shielding prevents EMI interference in sensitive automation systems.

• Compact 6-Pin Layout: Provides just enough contacts for small signal or power applications, saving panel space.

• Fail-Safe Coding: P2-coded variant prevents incorrect mating, adding an extra safety layer.

• Tool-Free Maintenance: Simple screw or crimp terminal access reduces installation and repair time.

• Environmental Protection: IP65 rating keeps out dust and water spray, suitable for industrial zones.

• Thermal Stability: Operates safely in extreme cold and hot environments.

• Universal Fit: Works with a wide range of HIMA modules and compatible control systems.

• Certified for Safety: Built to IEC and UL safety connector standards, meeting global compliance needs.

Frequently Asked Questions (FAQ)

1. What does the “P2” designation in the part number refer to?

   It indicates a specific coding position that prevents incorrect insertion with other connector types—ideal for safety-critical wiring.

2. Can I use this connector with standard multi-core signal cable?

   Yes, standard industrial-grade cables (shielded or unshielded) in the 6–12 mm range are supported.

3. Is this plug compatible with HIMA HIMatrix or HIMax series?

   Yes, the Z7138/3330/C6/P2 is designed for seamless integration with both HIMatrix and HIMax control systems.

4. How do I terminate the wires in the connector—do I need special tools?

   No special tools are needed. You can use either screw terminals (with a flat-head screwdriver) or crimp contacts, depending on the model variant.

5. Is this suitable for control panels located outdoors?

   Yes, provided it’s installed within a weatherproof enclosure or control cabinet, thanks to its IP65 protection.

6. Does the connector support both analog and digital signal transmission?

   Absolutely. It can carry analog (4–20 mA, ±10 V) or digital signals (0/24 V logic) depending on the connected equipment.

7. How do I ensure proper shielding continuity when installing?

   Ensure the cable shielding is connected properly to the grounding frame through the gland or shield clamp during wiring.

8. Are replacement contact pins or housings available separately?

   Yes. HIMA and authorized distributors offer individual connector parts for field servicing.

9. Can this connector be used in vibration-prone environments like rotating machinery panels?

   Yes, its locking mechanism and compact build make it vibration-resistant and secure in mobile or industrial machinery.

10. How long can I expect this connector to last under normal industrial use?

    With proper handling and correct mating/unmating procedures, the connector can last over 500 cycles, equivalent to several years of daily use.
