GE Fanu IC660EBA020 Analog I/O Modules

The GE Fanuc IC660EBA020 is a versatile Analog I/O Block designed to deliver high-precision analog signal acquisition and control within distributed automation systems. As part of the Genius I/O family, it is engineered for direct installation in field environments, allowing analog inputs and outputs to be located close to the sensors and actuators they serve.

This block supports a combination of 8 analog inputs and 8 analog outputs, both individually configurable for voltage or current modes. It offers extensive diagnostics, flexible configuration, and robust communication with the host controller, making it ideal for a variety of industrial applications requiring accurate, real-time analog processing.

Key Features

• 8 analog inputs and 8 analog outputs in one compact module

• Each channel independently configurable for voltage or current

• Input range: 0–10 V or 4–20 mA; Output range: 0–10 V or 4–20 mA

• Advanced diagnostics for open circuit, short circuit, and out-of-range

• Integrated Genius I/O network interface

• Fully isolated analog and logic sections

• Local and remote parameter configuration

• Status and fault indication via onboard LEDs

• Suitable for Class I, Division 2 hazardous environments

Technical Specifications

Industry Applications

• Water and Wastewater Treatment: For monitoring and controlling flow, pH, and chemical dosing.

• Food and Beverage Processing: Supports precise temperature and level control loops.

• Oil & Gas Facilities: Delivers reliable analog signal processing for field transmitters and actuators.

• Pharmaceutical Manufacturing: High-resolution analog control for sensitive production environments.

• Factory Automation: Enables scalable analog input/output for machine systems and production lines.

• HVAC and Environmental Systems: For feedback control of dampers, valves, and transducers.

Product Advantages

• Dual Functionality: Combines both analog inputs and outputs in one module to reduce system complexity.

• Channel Flexibility: Each input and output can be configured independently for current or voltage.

• High Accuracy: 12-bit resolution ensures excellent precision in both signal acquisition and output.

• Field Diagnostics: Built-in diagnostics reduce downtime by enabling fast fault detection.

• Network Efficiency: Communicates directly over the Genius I/O bus for efficient control architecture.

• Space Saving Design: Compact footprint ideal for distributed control panels.

• Industrial Durability: Operates reliably under vibration, temperature extremes, and harsh conditions.

Frequently Asked Questions (FAQ)

1. What is the input/output configuration of the IC660EBA020?

   It has 8 analog inputs and 8 analog outputs, all software-configurable.

2. Can each analog channel be configured independently?

   Yes, each channel can be set to either voltage or current mode via configuration.

3. What is the resolution of the module?

   It provides 12-bit resolution for both input and output channels.

4. Is this module compatible with other Genius I/O devices?

   Yes, it is fully compatible with the Genius I/O network and controllers.

5. How is the module configured?

   It can be configured using a handheld monitor or Genius configuration tools.

6. Does the block support fault detection?

   Yes, it detects open circuits, short circuits, and out-of-range signals.

7. Is the analog section isolated from the logic side?

   Yes, optical isolation is provided to protect against electrical interference.

8. Can the module be used in hazardous areas?

   Yes, it is compliant with Class I, Division 2 requirements when properly installed.

9. What’s the power supply requirement?

   It operates on an 18–30 VDC field power supply.

10. Does the IC660EBA020 support remote diagnostics?

    Yes, diagnostics can be accessed remotely via the Genius I/O network.
