Honeywell 8C-TAIMA1 51307171-175 Low-level Analog Input I/O Termination Assembly

The Honeywell 8C-TAIMA1 (51307171-175) is a low-level analog input I/O termination assembly designed for use with Honeywell Experion Process Knowledge System (PKS) and other process control systems. It serves as a critical interface module, facilitating precise and reliable termination and signal conditioning of low-level analog signals from various field transmitters and sensors.

Engineered for industrial environments, this termination assembly provides noise reduction, enhanced signal integrity, and secure wiring connections. It plays a pivotal role in ensuring accurate data acquisition and seamless communication between field instruments and control systems, especially in applications requiring high precision and stability.

Product Specifications

Applications

The Honeywell 8C-TAIMA1 is employed across various industries and process control environments, including:

• Process Automation: Accurate termination and conditioning of analog input signals from transmitters monitoring flow, pressure, temperature, and level in oil & gas, petrochemical, and refining operations.

• Power Generation: Analog signal management for turbine controls, boiler monitoring, and plant safety instrumentation.

• Water and Wastewater Treatment: Integration with sensors for flow and chemical dosing control.

• Pharmaceutical Manufacturing: Precise measurement input for critical control parameters.

• Chemical Processing: Signal isolation and noise reduction for high-integrity analog data transmission.

• Food & Beverage: Monitoring of analog instrumentation in hygienic process environments.

Advantages

• Reliable Signal Conditioning: Provides enhanced noise immunity and stable signal transmission, essential for accurate data capture.

• Secure Wiring Interface: Screw terminal blocks ensure firm, vibration-resistant electrical connections.

• Compact and Robust: Small form factor with durable construction suitable for harsh industrial settings.

• Easy Installation: Panel or rack mounting simplifies integration into existing systems.

• Wide Temperature Range: Operates reliably under extreme temperature conditions.

• Compatibility: Designed to seamlessly integrate with Honeywell’s Experion PKS and other DCS platforms.

• Enhanced Safety: Meets international certification standards, supporting industrial safety requirements.

• Maintenance Friendly: Clear labeling and accessible terminals reduce troubleshooting and downtime.

• Flexible Channel Support: Suitable for various channel configurations depending on system design.

• Long-term Availability: Backed by Honeywell’s support network and lifecycle management.

FAQ

1. What types of signals does the 8C-TAIMA1 support?

   It supports low-level 4-20 mA analog current input signals.

2. How is this termination assembly mounted?

   It can be mounted on a panel or rack depending on the installation environment.

3. What is the operating temperature range?

   The unit operates reliably between -20°C and +70°C.

4. Is it compatible with Honeywell’s Experion PKS system?

   Yes, it is designed for seamless integration with Experion PKS and other Honeywell DCS.

5. What are the dimensions and weight of the assembly?

   Dimensions are 220 x 120 x 228.6 mm, and weight is 0.6 kg.

6. Does it provide any signal conditioning or isolation?

   Yes, it includes built-in filtering and isolation to improve signal quality.

7. Can it handle high electrical noise environments?

   Yes, the assembly features shielding and grounding provisions for noise immunity.

8. What type of wiring connections does it use?

   It uses screw terminal blocks for secure and reliable wiring.

9. Is it certified for use in hazardous locations?

   Certification depends on configuration but it generally complies with CE and UL standards.

10. How many channels does it support?

    The number of channels varies based on the system configuration and application needs.
