Schneider 140XTS00200 Screw Terminal Block

The Schneider Electric 140XTS00200 is a high-performance Screw Terminal Block specifically designed for use with the Modicon Quantum automation platform. Acting as a reliable interface between field wiring and I/O modules, this terminal block is engineered to ensure safe, secure, and efficient connections in industrial control panels.

Its modular construction and robust design make it particularly well-suited for applications where wiring density, long-term reliability, and signal integrity are critical. Schneider’s engineering behind the 140XTS00200 ensures that every signal from sensors, actuators, or other field devices is transmitted cleanly and accurately to the control system.

Tailored for industrial environments, this terminal block is crafted from high-grade materials that provide excellent mechanical stability and resistance to vibrations. It ensures effortless installation and long-term maintenance while maintaining strict adherence to industry safety and connection standards.

Product Specifications

Product Applications

The 140XTS00200 Screw Terminal Block is primarily designed to serve industrial automation and control systems where secure, high-density wiring connections are required. It is widely used in the following applications:

• Process Control Systems

  In oil and gas, chemical, and water treatment plants, it facilitates precise signal transmission between field sensors and Quantum I/O modules.

• Discrete Manufacturing

  Connects input/output signals from production lines, such as conveyors, pick-and-place systems, and automated machinery.

• Electrical Substations

  Used to route and isolate control signals between field instruments and SCADA systems.

• Power Distribution Units

  Serves as a reliable interface point for connecting protection relays, switches, and monitoring systems.

• Building Automation Systems

  Links temperature sensors, HVAC controllers, and access control devices to centralized automation platforms.

• Transportation Infrastructure

  Facilitates connectivity for tunnel monitoring systems, railway control panels, and automated tolling systems.

Product Advantages

1. Robust Mechanical Design

   Built with durable thermoplastic materials that resist wear, vibration, and harsh environmental conditions.

2. Precision Terminal Configuration

   16-channel terminal configuration optimizes space utilization and reduces panel clutter.

3. Wide Wire Gauge Support

   Accepts a wide range of wire sizes, offering flexibility during installation and field rewiring.

4. Secure Screw-Clamp Mechanism

   Ensures vibration-resistant, corrosion-free connections over extended operational life.

5. Tool-Friendly Assembly

   Simplified wiring and disconnection process using standard screwdrivers and tools.

6. Compliance with Global Standards

   UL, CE, CSA, and RoHS certifications ensure it meets global industry safety and environmental standards.

7. Plug-and-Play with Quantum I/O Modules

   Seamless integration with Schneider Quantum I/O slots without additional adapters.

8. Thermal Stability

   Designed to operate reliably over a wide temperature range, minimizing failure risks in extreme environments.

9. Modular Expandability

   Enables system integrators to scale up field connections effortlessly as system complexity grows.

10. Compact Footprint

    Conserves panel space, essential in dense control cabinets where efficient layout matters.

FAQ

1. Is the 140XTS00200 compatible with all Modicon Quantum I/O modules?

   Yes, it is designed for direct integration with most standard Quantum discrete I/O modules.

2. Can I use this terminal block with analog signals?

   While primarily intended for discrete signals, it may be used with low-voltage analog wiring if properly shielded.

3. What type of wires are supported?

   It supports solid or stranded copper wires between 0.5 mm² and 2.5 mm² (20–14 AWG).

4. Does it come with labeling options?

   Yes, labeling strips are available for channel identification and wiring organization.

5. Is DIN rail mounting mandatory?

   No, it can also be directly mounted on the backplane or within a dedicated Quantum rack.

6. How are wires secured in this terminal block?

   Using a screw-clamp mechanism that ensures firm contact even under vibration.

7. Can it be reused after system disassembly?

   Yes, it is designed for long-term reuse and can withstand multiple wiring cycles.

8. What certifications does the product carry?

   It is UL listed, CE certified, CSA approved, and compliant with RoHS standards.

9. Can this be used in outdoor enclosures?

   Only if the enclosure provides protection against moisture and temperature extremes within specified limits.

10. Does Schneider offer a pre-wired version?

    Yes, some configurations may be offered pre-wired for large-scale OEM and project deployments.
