Schneider Electric 140CPU65150 Unity Processor

The Schneider 140CPU65150 is a 768 kB RAM, 166 MHz Unity processor that is part of the Modicon Quantum automation platform. It is a versatile and powerful PLC that can be used in a wide variety of applications, including machine control, process automation, and building automation.

Specifications

Main

• Range of Product: Modicon Quantum automation platform
• Product or Component Type: Unity processor

Complementary

• Clock Frequency: 166 MHz
• Number of Slots: 10, 16, 6, 4, 2
• Number of Racks: 2 (local)
• Number of Distributed I/O Station: 63 (1-3 Modbus Plus)
• Number of Remote I/O Station: 31 (2 S908 remote I/O), 31 (2 Ethernet Quantum remote I/O), 16 (2 Ethernet X80 remote I/O)
• Discrete I/O Number:
  • 31744 inputs, 31744 outputs (remote)
  • 8000 inputs, 8000 outputs (distributed – per network Modbus Plus)
  • Unlimited (26 slots max) – local
  • Unlimited (31 drops of 28 slots max) – Ethernet remote I/O
• Analogue I/O Number:
  • 500 inputs, 500 outputs (distributed – per network Modbus Plus)
  • 1984 inputs, 1984 outputs (S908 remote I/O)
  • Unlimited (26 slots max) – local
  • Unlimited (31 drops of 28 slots max) – Ethernet remote I/O
• Application Specific I/O: Accurate time stamping, Serial link, High-speed interrupt inputs, Counter
• Communication Service: Ethernet router
• Number of Optional Modules: 6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)
• Maximum Number of Connections:
  • 1 USB
  • 2 AS-Interface (distributed)
  • 4 AS-Interface (remote)
  • 6 Ethernet TCP/IP (local)
  • 6 Modbus Plus (local)
  • 6 Profibus DP (local)
  • 1 Modbus RS232/485 (Modbus/ASCII)
• Integrated Connection Type:
  • 1 Modbus Plus
  • 1 Ethernet TCP/IP
  • 1 Modbus
  • 1 USB
• Checks: Process control
• Memory Description:
  • Expandable 7168 kB – program with PCMCIA card
  • Expandable 8 MB – file storage with PCMCIA card
  • Internal RAM 768 kB
• Switch Function: Key switch memory port on/off
• Application Structure:
  • 1 cyclic/periodic master task
  • 1 periodic fast task
  • 128 I/O interrupt tasks
  • 128 interrupt tasks
  • 32 timer interrupt tasks
  • 4 auxiliary tasks
• Number of Instructions per ms:
  • 10.28 Kinst/ms 100% Boolean
  • 10.07 Kinst/ms 65% Boolean and 35% numerical
• System Overhead:
  • 0.2 ms fast task
  • 1 ms master task
• Bus Current Requirement: 2160 mA

Local Signalling

• For Ethernet activity (COM): 1 LED (green)
• For Ethernet collision: 1 LED (red)

Electrical Connection

• 1 female connector SUB-D 9 for connecting to the Modbus Plus network
• 1 connector RJ45 for connecting Ethernet network
• 1 connector RJ45 for connecting Modbus bus

Environment

• Product Certifications: Misc (Marine), UL, CE, CSA, GOST
• Standards: HazLoc

Ordering and Shipping Details

• Category: 18150-QUANTUM CONTROLLERS, HSBY, COMM.
• Discount Schedule: PC21
• GTIN: 3595862066402
• Returnability: No
• Country of Origin: FR

Packing Units

• Unit Type of Package 1: PCE
• Number of Units in Package 1: 1
• Package 1 Height: 4.33 in (11.0 cm)
• Package 1 Width: 7.28 in (18.5 cm)
• Package 1 Length: 12.80 in (32.5 cm)
• Package 1 Weight: 3.16 lb(US) (1.434 kg)
• Unit Type of Package 2: S04
• Number of Units in Package 2: 6
• Package 2 Height: 11.81 in (30.0 cm)
• Package 2 Width: 15.75 in (40.0 cm)
• Package 2 Length: 23.62 in (60.0 cm)
• Package 2 Weight: 19.84 lb(US) (9.0 kg)
