Honeywell CC-PDIH01 51405041-175 Digital Input Module

The Honeywell CC-PDIH01 51405041-175 is a high-voltage digital input module designed for the Experion Process Knowledge System (PKS) Series C platform. It provides 16 isolated high-voltage inputs for monitoring the on/off status of field devices. The module accepts inputs from 24 to 250 VAC or 24 to 300 VDC, making it suitable for a wide range of industrial applications. With a response time of less than 1 millisecond and an accuracy of 0.1%, the CC-PDIH01 ensures precise and timely data acquisition. It is certified for use in hazardous areas, including Class I, Division 2, Groups A, B, C, and D, as well as Class II, Division 1, Groups E, F, and G. ​

Product Specifications

Product Applications

The CC-PDIH01 module is ideal for monitoring digital signals in various industrial settings, including:​

• Oil and gas facilities

• Chemical processing plants

• Power generation stations

• Water and wastewater treatment plants

• Pharmaceutical manufacturing

• Food and beverage processing

• Pulp and paper mills​

Product Advantages

• High Voltage Input Range: Supports a wide range of input voltages, enhancing versatility.

• Fast Response Time: Ensures timely detection of input signal changes.

• High Accuracy: Provides precise input signal measurements.

• Isolated Channels: Each input channel is electrically isolated, improving system reliability.

• Hazardous Area Certification: Suitable for use in environments with explosive gases or dust.

• Compact Design: Space-saving form factor facilitates easy installation.

• Robust Construction: Designed to withstand harsh industrial conditions.​

Frequently Asked Questions (FAQ)

1. What is the primary function of the CC-PDIH01 module?

   • It monitors high-voltage digital input signals from field devices.​

2. What input voltage ranges does the module support?

   • It accepts 24 to 250 VAC or 24 to 300 VDC inputs.​

3. How many input channels are available?

   • The module provides 16 isolated input channels.​

4. Is the module suitable for hazardous environments?

   • Yes, it is certified for use in Class I, Division 2, Groups A-D, and Class II, Division 1, Groups E-G areas.​

5. What is the response time of the module?

   • It has a response time of less than 1 millisecond.​

6. Can the module be mounted on a DIN rail?

   • Yes, it supports DIN rail and standard 19-inch rack mounting.​

7. What is the operating temperature range?

   • The module operates between -40°C and +70°C.​

8. Is the module compatible with other Honeywell systems?

   • It is designed for use with the Experion PKS Series C platform.​

9. What certifications does the module have?

   • It is certified for hazardous area use as specified above.​

10. What is the power supply requirement?

    • The module requires a 24 VDC power supply and consumes 60 W.
