Honeywell TC-HAI081 HART Analog Input Module

Honeywell TC-HAI081 is an 8-channel HART analog input module designed for ControlLogix controllers. It offers isolated analog voltage, current, and HART signal conditioning suitable for various process applications. The module delivers high accuracy, low noise, and quick update times, making it well-suited for demanding environments.

Key Features

• 8 isolated analog input channels: Accommodates voltage, current, or HART signals.
• High accuracy: ±0.15% of full scale ensures precise measurements.
• Low noise: Maintains <2 µVrms for clean signal output.
• Fast update time: Provides updates in <5 ms for real-time monitoring.
• Wide operating temperature range: Functions optimally from -40 to 70°C (-40 to 158°F).
• Ease of use: Simplifies configuration and operation.
• Compatibility: Supports ControlLogix 5570, 5571, and 5580 controllers.

Applications

• Process control: Ideal for managing industrial processes.
• Machine control: Enhances the control of machinery.
• Environmental monitoring: Monitors environmental conditions with precision.
• Test and measurement: Facilitates accurate testing and measurement tasks.

Specifications

• Number of channels: 8
• Input type: Voltage, current, or HART
• Input range: -10 to 10 V, 4 to 20 mA, or HART
• Accuracy: ±0.15% of full scale
• Noise: <2 µVrms
• Update time: <5 ms
• Operating temperature range: -40 to 70°C (-40 to 158°F)
• Power consumption: 2.5 W
• Dimensions: 8.5 x 6.3 x 1.2 inches (216 x 160 x 30 mm)
• Weight: 1.2 lb (0.5 kg)
