Yokogawa YCB147-2 Terminal Block Assembly
Manufacturer:Yokogawa
Product Number:YCB147-2
Product Type:Terminal Block Assembly
Origin:Japan
Dimensions:145 mm × 42 mm × 115 mm
Weight:0.32 kg
Views:56
Payment Methods:T/T, PayPal, Western Union
Condition:New & In Stock
Warranty:1 Year
Lead Time:1-3 Working Days
Certificate:COO
Courier partners:DHL, UPS, TNT, FedEx and EMS.
Business hours:7*24
Product Description
The Yokogawa YCB147-2 is designed for plants that demand clean, dependable wiring between system I/O modules and field instrumentation. Built with Yokogawa’s typical attention to robustness, this terminal block assembly ensures stable signal routing, simplified maintenance, and reduced installation complexity.
Whether you are upgrading a legacy DCS, extending I/O capacity, or replacing damaged field termination hardware, the YCB147-2 offers the reliability and mechanical precision required for long, trouble-free operation. Its durable construction and clearly defined terminals make it a trusted choice for engineers who value clarity, consistency, and long-term availability.
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Terminal Block Assembly |
| Compatibility | Yokogawa CENTUM & ProSafe series (specific modules dependent) |
| Terminal Count | Multi-point field termination (model-specific configuration) |
| Connection Type | Screw-type terminal strip |
| Insulation Strength | High-durability insulated PCB |
| Operating Voltage | Suitable for low-voltage signal and control wiring |
| Signal Support | AI, AO, DI, DO (module dependent) |
| Mounting | Panel or rack-mounted bracket |
| Operating Temperature | –10°C to +55°C |
| Storage Temperature | –25°C to +85°C |
| Humidity | Up to 90% RH, non-condensing |
| Dimensions (H × W × D) | 145 mm × 42 mm × 115 mm |
| Weight | 0.32 kg |
| Build Material | Industrial-grade PCB with reinforced insulation and corrosion-resistant terminals |
Applications
-
Field cable termination for Yokogawa I/O modules
-
DCS expansion and modernization projects
-
Instrumentation signal routing for AI/AO/DI/DO channels
-
Panel integration for industrial automation
-
Replacement terminal blocks for maintenance and system reliability upgrades
Advantages
-
Consistent Signal Integrity: Reduces wiring errors and keeps field connections clean.
-
Durable Terminal Construction: Engineered for harsh industrial environments.
-
Easy Field Maintenance: Clear labeling ensures fast troubleshooting.
-
Wide System Compatibility: Supports a variety of CENTUM I/O modules.
-
Stable Long-Term Availability: Ideal for plants managing mixed-generation equipment.
FAQs(10)
-
Is the YCB147-2 compatible with multiple Yokogawa control systems?
Yes, it supports selected CENTUM and ProSafe modules depending on your I/O configuration.
-
Can this terminal block handle both analog and digital signals?
It can, depending on the paired I/O module.
-
Are the terminals clearly labeled?
Yes, the layout is designed for straightforward wiring and maintenance.
-
Does the assembly include protective insulation?
It features reinforced insulation suitable for industrial environments.
-
Can it be panel-mounted?
Yes, the design supports secure panel or bracket mounting.
-
Is it suitable for field retrofit projects?
Absolutely—frequently used to upgrade aging termination hardware.
-
Does it require calibration?
No calibration is needed; it is a passive wiring interface.
-
Is it resistant to vibration or harsh operating conditions?
Yes, the terminals and PCB structure are built for stable operation.
-
Does the YCB147-2 support shielded wiring?
Shielding method depends on system grounding practices; terminals support standard instrumentation cable routing.
-
How long is its expected service life?
With proper installation, it offers long-term operation with minimal maintenance needs.
