General Electric IS200IGPAG2AED IGBT Gate Protection & Control Module
Manufacturer:GE Fanuc
Product Number:IS200IGPAG2AED
Product Type:Gate Drive Interface Module
Origin:USA
Dimensions:213 mm × 142 mm × 36 mm
Weight:0.79 kg
Views:80
Payment Methods:T/T, PayPal, Western Union
Condition:New & In Stock
Warranty:1 Year
Lead Time:1-3 Working Days
Certificate:COO
Courier partners:DHL, UPS, TNT, FedEx and EMS.
Business hours:7*24
Product Description
The GE IS200IGPAG2AED module is an IGBT gate protection and control board developed for Mark VI industrial drive and turbine power electronics. Its role is to manage gate drive signals, supervise switching behavior, and protect power semiconductor devices from electrical stress. This module is frequently selected for refurbishment programs and long-term maintenance contracts where reliability, precise switching control, and stable protection logic are essential.
Technical Specifications and Form Factor
| Specification | Details |
|---|---|
| Brand | GE |
| Model | IS200IGPAG2AED |
| Module Type | IGBT Gate Protection / Gate Drive Interface Module |
| Functional Purpose | Gate control, monitoring, protection feedback |
| Supported Hardware | IGBT-based power assemblies |
| Protection Features | Overcurrent sensing, gate fault monitoring |
| Backplane Interface | Mark VI platform communication path |
| Nominal Voltage | 5V / 15V control-level operation |
| Dimensions (L × W × H) | 213 mm × 142 mm × 36 mm |
| Weight | 0.79 kg |
| Operating Temperature | -20°C to 65°C |
| Installation | Mark VI industrial drive rack |
Application Relevance for Power Electronics
The IS200IGPAG2AED is deployed within GE industrial drive systems and turbine control cabinets that rely on IGBT-based switching hardware. These systems include:
-
Medium-voltage industrial drives
-
Turbine power converter cabinets
-
High-frequency switching protection networks
-
Power module gate monitoring systems
-
Upgrades replacing earlier IGPAG1 or early G2 variants
Its precise gate control helps reduce switching stress, improve device lifespan, and stabilize converter operation across varying load conditions.
Operational Advantages for Engineers and Integrators
The module provides a strong combination of signal integrity and protective oversight. With its integrated fault-sensing routines, it assists in preventing thermal runaway and protects IGBTs from damaging transient currents. Integrators appreciate its predictable timing characteristics, which help maintain synchronization across parallel switching paths. The board’s construction also supports long-term field reliability, reducing the need for premature replacement.
FAQs
-
What does the IS200IGPAG2AED primarily control?
It manages gate drive commands and protective monitoring for IGBT power devices.
-
Is it part of the Mark VI or Mark VIe ecosystem?
It is designed mainly for Mark VI industrial drive and turbine electronics.
-
Can it replace G1 revisions?
In certain configurations yes, but compatibility must be verified per rack design.
-
Does it include built-in overcurrent monitoring?
Yes, the module supervises fault feedback from IGBT hardware.
-
Is firmware required for operation?
No—its behavior is defined by hardware architecture and backplane interaction.
-
What conditions indicate a failing gate board?
Unstable switching, repeated fault triggers, or loss of gate drive signal.
-
Does it require calibration?
Generally no; gate characteristics are factory-defined.
-
Is it suitable for high-frequency switching?
Yes, within GE’s recommended switching ranges.
-
Can environmental heat impact performance?
Only if the temperature exceeds the specified operating limit.
-
Is field repair recommended?
No, full module replacement is the standard maintenance practice.
