ABB SAFT160F380 Power Supply Module

The ABB SAFT160F380 Power Supply Module is a high-voltage industrial-grade power unit designed for use in ABB DCS (Distributed Control Systems) such as Symphony Plus, Advant OCS, and other ABB control platforms. It provides a stable 380V AC input to DC conversion for powering controllers, I/O modules, and field instrumentation within automation systems that demand precision, reliability, and uninterrupted performance.

Engineered to meet the requirements of mission-critical applications, the SAFT160F380 ensures continuous operation under harsh industrial environments with advanced protective circuitry, high electrical efficiency, and thermal stability. It is commonly found in power generation, chemical plants, steel mills, oil and gas, and process automation systems where stable DC power is essential.

Technical Specifications

System Applications

• Thermal and Hydro Power Plants: Powers DCS controllers, analog I/O, and relay systems.

• Oil & Gas Refineries: Provides stable power to field communication and safety systems.

• Steel and Metal Processing Plants: Maintains continuous power for motor control and instrumentation.

• Water Treatment Facilities: Supports process automation systems for water quality and flow management.

• Chemical and Pharmaceutical Production: Ensures reliable control loop power for precise dosing and batching.

• Marine Automation Systems: Resistant to vibration, humidity, and saline environments.

Performance Advantages

• High Input Voltage Tolerance: Handles 380–415 VAC input for flexible deployment.

• Regulated DC Output: Maintains consistent voltage under variable load conditions.

• Comprehensive Circuit Protection: Guards against overload, surge, and overheating.

• Compact and Efficient Design: Saves space in crowded control cabinets.

• Industrial Durability: Built with corrosion-resistant aluminum and industrial-grade components.

• Silent Operation: Passive cooling eliminates fan noise and mechanical failure.

• High Electrical Efficiency: Reduced energy loss for lower operational cost.

• Global Compatibility: Certified for worldwide industrial standards.

• Simplified Maintenance: Front-facing LEDs and terminal layout for easy servicing.

• Long-Term Reliability: Proven performance under continuous 24/7 operation.

FAQs

1. Q: What is the input voltage range of the SAFT160F380?

   A: It operates on a 380–415 VAC three-phase supply.

2. Q: What is the DC output voltage?

   A: The standard regulated output is 24 VDC.

3. Q: Does this power module support overload protection?

   A: Yes, it has overcurrent, overvoltage, and short-circuit protection built-in.

4. Q: Can this module be used in redundant configurations?

   A: Yes, it supports parallel or redundant operation for high availability.

5. Q: What is the typical power output capacity?

   A: It delivers 240 W continuous output power.

6. Q: How is cooling achieved?

   A: Through natural convection without fans.

7. Q: What type of isolation is provided?

   A: 2000 VDC isolation between input and output circuits.

8. Q: What are the module’s dimensions and weight?

   A: 135 × 70 × 160 mm, approximately 0.95 kg.

9. Q: Is it compatible with ABB Symphony Plus systems?

   A: Yes, it integrates seamlessly with ABB DCS platforms.

10. Q: Can it operate continuously in high-temperature environments?

    A: Yes, up to +55°C under rated load conditions.
