General Electric DS200LRPBG1AAA Resolver Board

GE DS200LRPBG1AAA is a resolver board developed by GE as part of the Mark V control system. The board works by receiving analog signals from a resolver (a type of rotary transformer) and converting those signals into a digital format that can be used by a control system such as a programmable logic controller (PLC) or motor controller.

The resolver is an electromagnetic sensor that converts the mechanical rotation angle into an electrical signal related to the mechanical rotation angle. With analog-to-digital conversion capabilities, the microprocessor on the board converts the received analog signal into a digital signal.

Fuctions & Features

• Signal Conversion: The GE DS200LRPBG1AAA resolver is an electromagnetic sensor that converts the mechanical angle of rotation into an electrical signal that is a function of the mechanical angle of rotation.

• Analog-to-Digital Conversion: The microprocessor in the GE DS200LRPBG1AAA resolver converts the analog signal received into a digital signal.

• System Assurance: The GE DS200LRPBG1AAA resolver maintains the system by continuously monitoring the position of the rotor. Once any anomaly in the rotor's motion is detected, the information is immediately communicated to the control system.

Specification
