ABB 70AB01C-ES HESG447224R2 Binary Signal Output Module
Manufacturer: ABB
Product Number: 70AB01C-ES (HESG447224R2)
Category: Binary Signal Output Module
System Compatibility: ABB Procontrol P13 system
Application: Process control and supervision in industrial automation systems
Product Description
The ABB 70AB01C-ES HESG447224R2 is a state-of-the-art digital output module, designed for process control and supervision in industrial automation systems. It is part of the ABB Procontrol P13 system, which includes a comprehensive range of I/O modules tailored for analog, digital, and pulse-based input and output signals. The 70AB01C-ES module is specifically designed to drive electronic inputs of external devices, relays, and lamps, making it ideal for applications where digital outputs are required for controlling relays and other loads such as lamps in industrial processes.
This module is a direct replacement for older digital output modules in the Procontrol P13 system, offering enhanced flexibility, ease of configuration, and superior performance. By using advanced DSP/FPGA-based technology, it provides low-maintenance, durable, and high-performance solutions. It is configured and monitored using the P13 Configurator software, which simplifies commissioning, maintenance, and fault diagnosis. Additionally, the module supports simulation and forcing of channels for troubleshooting, enabling easy loop checks after maintenance.
Key Benefits
- Complete Software Configuration:The module can be fully configured through the P13 Configurator software, removing the need for manual switch and jumper settings. This results in faster setup and improved reliability.
- Flexible I/O Channel Configuration:The 70AB01C-ES module offers 16 output channels that can be individually configured for different types of outputs such as driving input cards, relays, and lamps.
- Seamless Integration:All previous Procontrol P13 digital output modules can be seamlessly replaced with this new module family, ensuring backward compatibility while providing enhanced features.
- Advanced Technology:The module uses cutting-edge DSP/FPGA technology, ensuring high durability and minimal maintenance requirements.
- Comprehensive Fault Detection and Annunciation:The module includes advanced fault detection capabilities, such as overcurrent protection, thermal shutdown, and voltage disruptions. Fault conditions are clearly indicated by an alarm LED on the master module.
- Simulation and Forcing:Each output channel can be individually simulated or forced directly from the P13 Configurator tool, simplifying troubleshooting and commissioning.
Product Features
- Output Channels: 16 digital output channels
- Channel Type: 24V DC solid-state bipolar driver
- Output Load Types: Electronic module inputs, relays, lamps
- Configuration Interface: Front panel RS232 (custom phone jack) for easy connection and setup
- Memory: EEPROM for onboard configuration storage
- Simulation Functions: Individual forcing and simulation of output channels
- Fault Detection: Includes communications error, voltage source disruptions, over-current conditions, and thermal shutdown
- Alarm Output: Digital alarm output (+24V DC) with a visual master module ALARM LED indicator
- Bus Interface: Full local bus addressing, supporting both normal and special address ranges
- Power Supply: Powered via the P13 rack with a voltage range of +19.5V to +30V DC
Detailed Technical Parameters
| Parameter | Description |
|---|---|
| Model | 70AB01C-ES HESG447224R2 |
| Channels | 16 Output Channels |
| Channel Type | 24V DC Solid-State Bipolar Driver |
| Output Types | Electronic Inputs, Relays, Lamps |
| Output Response Time | 6µs (delay from command to output) |
| Local Bus Interface | Full local bus address range (normal and special) |
| Data Format | 16-bit Binary Word |
| Power Supply | Powered via P13 Rack |
| Operating Voltage | Min: +19.5V DC, Max: +30V DC |
| Power Consumption | Typical: 2.1W, Max: 5.3W (excluding channel source current) |
| Current Draw (Max Source) | 100 mA (maximum source current per channel) |
| Alarm Output Load | 3 mA |
| Fault Output Capacity | ≤ 10 mA (protected against back feed and short circuit) |
| Configuration Interface | RS232 (custom phone jack) for easy access and setup |
| Fault Detection | Communications error, voltage disruption, over-current, thermal shutdown |
| Fault Annunciation | Visual Alarm LED on the master module, I/O SME2 digital alarm output |
| Simulation Functions | Individual channel forcing and simulation via P13 Configurator tool |
| Dimensions (W x H x D) | 180 x 120 x 90 mm |
| Weight | 1.5 kg |
| Enclosure Type | Steel enclosure, IP65 rated for protection against dust and water |
| Temperature Range (Operating) | -20°C to +60°C |
| Temperature Range (Storage) | -40°C to +85°C |
Fault Detection and Behavior
The 70AB01C-ES module comes equipped with advanced fault detection capabilities, including:
- Communications Error: If a communication fault is detected, the module will set the output to its last good state.
- Voltage Source Disruptions: The module can handle voltage source fluctuations and will alert the user to any disruptions.
- Overcurrent Protection: The module provides protection against overcurrent conditions, ensuring that the connected devices are not damaged.
- Thermal Shutdown: The module includes thermal protection to shut down the device in the event of overheating.
Fault conditions are clearly annunciated through the visual master module ALARM LED, and an I/O SME2 digital alarm output is available for remote monitoring.
Installation and Maintenance
The 70AB01C-ES module is designed for easy installation and maintenance. It uses a modular design, which allows for seamless integration with other Procontrol P13 system components. The configuration interface is accessible via the front panel RS232 port, simplifying the setup process. Furthermore, the P13 Configurator tool can be used to monitor the module, perform diagnostics, and configure it according to application needs.
During regular maintenance, users can utilize the simulation and forcing capabilities in the P13 Configurator to test individual output channels. This ensures that all outputs function as expected and allows for easy troubleshooting in case of faults.
Applications
The ABB 70AB01C-ES HESG447224R2 Binary Signal Output Module is ideal for use in a wide variety of industrial applications, including:
- Process Control: Used for controlling relays and electronic devices in process control systems.
- Supervision and Monitoring: Ideal for process supervision where output states must be monitored and controlled.
- Equipment Control Systems: Perfect for controlling devices such as lights, relays, and input cards in equipment control applications.
- Alarm and Safety Systems: Can be integrated into alarm and safety systems where clear fault detection and annunciation are required.
The combination of robust fault detection, high configurability, and ease of use makes the ABB 70AB01C-ES HESG447224R2 an excellent choice for complex automation and control systems.
