GE Fanuc IC693MDL230 Isolated Input Module
Manufacturer: GE Fanuc
Product Number: IC693MDL230
Category: 8-point Isolated AC Input Module (Series 90-30)
Number of Channels: 8 isolated input channels
Input Voltage: 120 VAC
System Compatibility: GE Fanuc Series 90-30 PLC system
Product Description
The GE Fanuc IC693MDL230 is an 8-point isolated AC digital input module designed for use within the Series 90-30 Programmable Logic Controller (PLC) system. This module provides eight individually isolated input channels for monitoring 120 VAC field devices such as switches, sensors, and pushbuttons. Its isolated input design ensures high noise immunity and protects both the PLC and field devices from electrical disturbances, making it ideal for applications in electrically noisy industrial environments.
Key Features
-
Individually Isolated Inputs–Each of the 8 input points is electrically isolated from the others
-
120 VAC Input–Designed to monitor standard industrial voltage-level AC signals
-
High Noise Immunity–Suitable for use in environments with high electromagnetic interference
-
LED Status Indicators–Provides visual indication of each input’s on/off status
-
Direct Slot Installation–Fits directly into any I/O slot of a GE Series 90-30 PLC baseplate
-
Reliable Operation–Designed for long-term use in demanding industrial control systems
Technical Specifications
Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 142 x 30 x 130 mm |
| Weight | 0.18 kg |
Electrical Characteristics
| Item | Specification |
|---|---|
| Input Points | 8 individually isolated channels |
| Input Voltage Range | 0–132 VAC (nominal: 120 VAC) |
| Frequency Range | 47–63 Hz |
| Input Current | 7 mA at 120 VAC (typical) |
| Isolation Protection | 1500 V RMS channel-to-channel and channel-to-ground |
| Input Impedance | Approx. 15 kΩ |
Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95% RH (non-condensing) |
| Vibration Resistance | Conforms to GE industrial standards |
System Compatibility
| Item | Specification |
|---|---|
| Compatible Systems | GE Fanuc Series 90-30 PLCs |
| Mounting Type | Standard I/O slot on Series 90-30 rack |
| Programming Tools | Proficy Machine Edition, Logicmaster 90 |
Industry Applications
-
Power and Utilities–Monitors status of AC-powered switches, relays, and breakers
-
Manufacturing–Interfaces with operator panel controls and AC sensors
-
Oil & Gas–Provides AC input signal detection in harsh process environments
-
Water & Wastewater–Enables input acquisition from level sensors and pump switches
-
Building Automation–Integrates AC control signals from facility systems
The GE Fanuc IC693MDL230 Isolated Input Module is a reliable and robust solution for AC signal monitoring in automation systems. Its isolated inputs and rugged design make it a critical component in applications demanding signal integrity and system protection within GE’s Series 90-30 control platform.
