The Yokogawa UP55A-001-11-00 is an advanced digital controller. It ensures precise temperature control and process automation. Part of the UP series, it offers high functionality and ease of use. It provides robust performance suitable for various industrial settings.

Technical Specifications

• Input Type: Universal input supports thermocouples, RTDs, voltage, and current signals.
• Control Output: Relay, SSR driver, current, or voltage output.
• Display: Dual 5-digit LED display shows process variable (PV) and setpoint (SP).
• Control Mode: PID control with auto-tuning and fuzzy logic.
• Communication: RS-485 MODBUS RTU protocol.
• Power Supply: 100-240 VAC, 50/60 Hz.
• Operating Temperature: -10°C to +50°C.
• Mounting: DIN rail or panel mount.
• Dimensions: 48 mm x 48 mm x 100 mm.
• Weight: Approximately 200 grams.
• Certifications: CE, UL.

Key Features

• PID Control: Provides precise temperature control and stability.
• Auto-tuning: Adjusts PID parameters automatically for optimal performance.
• Fuzzy Logic: Enhances control accuracy, reducing overshoot and undershoot.
• Communication: Integrates into larger control systems via RS-485 interface.
• Versatile Input: Compatible with multiple sensor types for broad application use.
• Compact Design: Small footprint allows easy installation in confined spaces.

Applications

• Temperature Control: Ideal for ovens, furnaces, and thermal processing equipment.
• Process Automation: Suitable for chemical, pharmaceutical, and food processing industries.
• HVAC Systems: Used in heating, ventilation, and air conditioning systems for precise environmental control.

Applications

• Process Control: Suited for chemical processing, food and beverage production, pharmaceuticals, and more.
• Temperature Control: Controls temperature in kilns, furnaces, and environmental chambers precisely.
• Manufacturing Automation: Integrates with automated systems for efficient production processes.
