The CC-PAIX02 is an advanced high-level analog input module designed to support 16 channels of either differential or single-ended inputs. It is a versatile solution suitable for measuring a wide range of signals, including temperature, pressure, flow, and level.

Key Features

• Accommodates 16 channels of either differential or single-ended input.
• High-resolution 16-bit A/D converter for precision.
• Exceptional common mode rejection ratio of 70 dB.
• Compatible with 4-20 mA current loop inputs.
• Accepts voltage inputs ranging from 0 to 5 V.
• Optional HART communication capability.

Technical Specifications

• Input Voltage Range: 0 to 5 V, 1 to 5 V, 0.4 to 2 V, 4-20 mA (via 250 Ω resistor)
• Input Current Range: 4 to 20 mA
• Common Mode Voltage Range: -6 to +5 V peak
• Common Mode Rejection Ratio: 70 dB
• A/D Converter Resolution: 16 bits
• Sampling Rate: 100 Hz
• Communication: Optional HART support
