The GE Fanuc IC697CMM742-HK is an Ethernet interface module designed for use in GE Fanuc Series 90-70 programmable logic controller (PLC) systems. It enables high-speed communication between PLCs and other Ethernet-based devices, ensuring efficient data transfer across a network. The module supports a variety of Ethernet connections, making it versatile for different industrial automation applications such as factory automation, process control, and remote monitoring.

Technical Specifications

• Module Type: Ethernet Interface Module for GE Fanuc Series 90-70 PLC systems
• Ethernet Connection Types:
  • 10BASE5
  • 10BASE2
  • 10BASET
  • 10BASEF
  • 10BROAD36
• Network Port: Standard 15-pin AUI network port
• Operating Voltage:
  • +5 VDC
  • +12 VDC
• Current Draw:
  • 2.0 Amps (typical) at +5 VDC
  • 0.5 Amps (maximum) at +12 VDC when powering an external AUI transceiver
• Internal Fuse:
  • 5 x 20mm, 250V, 1.0A, slow-acting
• Installation: 1 slot in the PLC CPU rack
• Restart Method: Pushbutton reset
• Weight: 1.19 lbs
• LED Indicators:
  • Status LEDs for module status
  • LEDs for network activity
  • LEDs for serial communication status
• Firmware: Pre-loaded firmware for quick operation and integration
