Yokogawa A2SMX801-S130 I/O Signal Adaptor

The Yokogawa A2SMX801-S130 is a pass-through I/O signal adaptor designed for Yokogawa’s N-IO system. It connects field instruments and sensors to the control system, offering essential I/O capabilities. Note that this device does not provide electrical isolation.

Key Features and Benefits

• Pass-through Functionality: Connects field instruments directly to the control system.
• Basic I/O: Delivers essential I/O capabilities for diverse applications.
• Compact Design: Saves space within control panels.
• Easy Installation: Mounts and connects easily.

Technical Specifications

• Type: Pass-through I/O signal adaptor
• Isolation: Non-isolated
• Mounting: See “LIMITATIONS AND PRECAUTIONS FOR INSTALLATION” in the GS of the N-IO System Overview (GS 33J62A10-01EN).
• Signal Connection: Refer to the TI “CENTUM VP Installation Guidance” (TI 33J01J10-01EN).

Additional Notes

• Channels among the A2SMX801-S130, A2SDV105, A2SDV505, and A2SMX802 adaptors are not isolated when mounted together.
• For detailed specifications, consult the product datasheet (GS 33J62F30-01EN).

Applications

The A2SMX801-S130 is suitable for various industrial automation applications, including:

• Process Control
• Manufacturing
• Oil and Gas
• Power Generation
