The ABB AF C094 AE02 HIEE200130R0002 is a high-performance ARCnet communication interface module, designed to support data transmission and real-time communication within industrial automation systems. Engineered by ABB, a world-renowned leader in power and automation technologies, this module is used primarily in distributed control systems (DCS) and industrial networks that require stable, deterministic data exchange.

ARCnet, known for its reliability and speed in harsh environments, is ideal for mission-critical process automation applications. This ABB interface panel acts as a bridge between control devices and other components over the ARCnet network. It ensures efficient data distribution and facilitates integration across large-scale plant operations, helping industries achieve superior process visibility, coordination, and control.

Technical Specifications

Applications

The ABB AF C094 AE02 ARCnet Control Panel is commonly deployed in a wide range of industrial sectors where dependable communication is critical. Common application areas include:

• Distributed Control Systems (DCS) for large-scale industrial automation

• SCADA systems requiring reliable data exchange between field and supervisory layers

• Communication backbone in power plants and substations

• Data synchronization for chemical and pharmaceutical production lines

• Coordinated control in metallurgy and mining operations

• Factory automation environments using legacy ARCnet networks

• Process plants requiring robust networking over long distances with high noise immunity

Product Advantages

• Reliable ARCnet Communication: Supports deterministic and time-critical data transfers within distributed systems.

• Dual Port Interface: Allows connection to multiple devices or network segments, enhancing flexibility and scalability.

• Compact and Robust: Designed for installation in industrial environments with limited space and harsh conditions.

• Ease of Integration: Compatible with existing ARCnet infrastructures and ABB control system architecture.

• Minimal Downtime: High electromagnetic immunity and sturdy design reduce risks of network interruptions.

• Clear Diagnostics: LED indicators help in real-time monitoring of communication status and fault detection.

• Low Power Consumption: Efficient 24 VDC operation with reduced heat generation, minimizing energy footprint.

• Extended Temperature Range: Suitable for environments with fluctuating ambient temperatures.

• Long Service Life: Designed for continuous operation with minimal maintenance requirements.

• Standards Compliant: Certified to meet global industrial safety and performance regulations.

Frequently Asked Questions (FAQ)

1. What is the primary function of the AF C094 AE02 ARCnet Control Panel?

It serves as a communication interface for ARCnet-based networks, enabling data exchange between controllers, I/O modules, and supervisory systems.

2. What type of networks is it compatible with?

The device is designed for ARCnet networks using coaxial (BNC) or twisted pair cabling.

3. What communication speed does it support?

It operates at the standard ARCnet speed of 2.5 Mbps, suitable for time-critical industrial applications.

4. Can this module be used in high-temperature environments?

Yes, it operates in temperatures ranging from -20°C to +60°C and can be stored at even lower temperatures.

5. Is it compatible with ABB Symphony or Advant DCS systems?

Yes, it is typically used within ABB’s DCS platforms including Symphony and Advant series.

6. Does it have LED indicators?

Yes, LED lights indicate power status and communication activity, aiding diagnostics and troubleshooting.

7. What kind of mounting is supported?

It can be installed on a panel or rack, depending on system design requirements.

8. Is this product suitable for modern Ethernet networks?

No, ARCnet and Ethernet use different protocols. However, it is suitable for legacy or specialized ARCnet systems.

9. What kind of protection does it have against interference?

The module is EMI/EMC-compliant, making it resilient to industrial electrical noise and cross-talk.

10. What maintenance is required?

Periodic inspection for dust, cable integrity, and status LED check is recommended. Otherwise, it is largely maintenance-free.
