The Ovation 5X00059G01 Analog Input Module is designed for Ovation Distributed Control Systems (DCS), providing accurate acquisition of analog signals from field instruments. It allows precise measurement of temperature, pressure, flow, and other process variables, enabling reliable process monitoring and control.

Key Features

• High-accuracy analog signal acquisition for process control

• Compatible with Ovation DCS platforms

• Supports multiple analog input channels

• Robust design for industrial environments

• Rack-mountable and modular for flexible installation

• High signal integrity with noise rejection

• Long-term stable performance for continuous operation

Technical Specifications

Industry Applications

• Power generation – temperature, pressure, and flow monitoring

• Oil & gas – process instrumentation signal acquisition

• Petrochemical and chemical – continuous process monitoring

• Industrial manufacturing – machinery and process variable measurement

• Water & wastewater – pump, valve, and tank monitoring

Advantages

• Provides high-accuracy analog signal acquisition for reliable control

• Seamlessly integrates with Ovation DCS for efficient process automation

• Modular design ensures easy installation and maintenance

• High signal integrity and noise rejection support stable operation

• Long-term stable performance in industrial environments

• Rack-mounted design simplifies system expansion and upgrades

Frequently Asked Questions (FAQ)

Q1: What is the main function of the 5X00059G01 module?

It acquires analog signals from field instruments for process monitoring and control.

Q2: Which systems is it compatible with?

It is compatible with Ovation Distributed Control Systems (DCS).

Q3: How many input channels does it support?

It typically supports 4–8 configurable analog input channels.

Q4: What signal types can it measure?

Voltage (±10 VDC) and current (0–20 mA / 4–20 mA) signals.

Q5: What is the accuracy of the module?

±0.1% of full scale.

Q6: What is the operating temperature range?

0 °C to +60 °C.

Q7: How is the module mounted?

Rack-mounted within the Ovation control cabinet.

Q8: What are its approximate dimensions and weight?

Dimensions are 100 × 60 × 22 mm; weight are 1.36 kg.

Q9: Does it provide stable performance in industrial environments?

Yes, it is designed for high stability and noise rejection.

Q10: Which industries commonly use this module?

Power generation, oil & gas, petrochemical, industrial manufacturing, and water & wastewater.
