The Yokogawa F3YD08-6A Output Module is a high-performance component designed for use in the Yokogawa FA-M3 series of PLC systems. This module provides reliable digital output functionality, ensuring fast, precise, and stable signal transmission to external devices such as actuators, relays, and indicators. It is widely adopted in industrial automation systems where dependable and high-speed output is critical.

Product Advantages

• High Reliability – Built with robust electronic components to ensure stable performance in demanding industrial environments.

• High-Speed Response – Supports fast digital output switching, enabling precise process control.

• Compact Design – Space-saving module with optimized layout for control cabinets.

• Easy Integration – Fully compatible with Yokogawa FA-M3 PLC systems for seamless expansion.

• Flexible Output Capacity – Capable of driving various external loads such as solenoids and contactors.

• Low Maintenance – Designed with durable components to reduce downtime and maintenance costs.

Technical Specifications

Product Applications

• Factory Automation – Controlling actuators, relays, and robotic mechanisms.

• Process Control Systems – Output control for valves, pumps, and motors.

• Manufacturing Lines – Digital output signaling for production equipment.

• Energy Systems – Monitoring and controlling power distribution equipment.

• Infrastructure Automation – Used in utilities, transportation, and building automation systems.

FAQ

Q1: What type of loads can the F3YD08-6A safely drive?

A1: It can drive DC loads such as solenoids, relays, contactors, and small DC motors, provided they are within the rated current and voltage.

Q2: Does this module provide output isolation?

A2: Yes, it has optical isolation to protect the CPU and other modules from electrical noise and faults.

Q3: What is the maximum current rating per channel?

A3: Each output channel can handle up to 0.5 A at 24 V DC.

Q4: Can multiple output channels be used simultaneously?

A4: Yes, all channels can operate simultaneously as long as the total current does not exceed the module’s limits.

Q5: What happens if an overload occurs on an output channel?

A5: The module has internal protection features, but external fuses or circuit breakers are recommended for safe operation.

Q6: How fast is the output switching response?

A6: The response time is less than 1 ms, making it suitable for high-speed control applications.

Q7: Is this module hot-swappable within the FA-M3 system?

A7: No, the module should be replaced only when the system is powered down to prevent damage.

Q8: Does the F3YD08-6A support diagnostic functions?

A8: Yes, it provides output status indicators via LEDs for easy troubleshooting.

Q9: Is external power required for the outputs?

A9: Yes, external 24 V DC power is required for driving connected loads.

Q10: Can it be used in redundant PLC configurations?

A10: Yes, it is compatible with redundant system designs within the FA-M3 framework.
