DANAHER MOTION Q117U-3 Product Introduction

Q117U-3 is a high-performance stepper motor launched by Danaher Motion, designed for high-precision positioning and dynamic control scenarios, suitable for fields such as medical equipment, industrial automation, semiconductor manufacturing, and precision instruments. This product combines the advantages of Danaher Drive in electromagnetic design, materials science, and intelligent control technology to provide a stable and reliable motion control solution.

Main features and advantages

High precision positioning: Adopting hybrid stepping technology with a step angle of 1.8 °, it can achieve a precision of 0.09 ° after subdivision, meeting the requirements of micrometer level positioning.

Low vibration and noise: Optimize the rotor magnetic circuit and bearing structure, with no-load operation noise below 40dB, reducing mechanical vibration interference.

Wide voltage compatibility: Supports 12-48VDC input voltage, adapts to complex power environments, and enhances system flexibility.

High dynamic response: The maximum speed can reach 2000 RPM, and the acceleration and deceleration time can be adjusted to adapt to high-speed motion and frequent start stop scenarios.

Environmental adaptability: Protection level IP54, tolerant to mild dust and humidity environment, working temperature range -20 ° C to 70 ° C.

Technical specifications

Parameter specification description

Rated voltage 24VDC (recommended)

Rated current 3A (continuous)

Output torque 1.2 N · m (continuous)

Step angle 1.8 ° (subdivided to 0.09 °)

Rotor inertia 3.5 g · cm ²

Shaft diameter size of 8mm (standard)

Weight 280g (including shell)

Application areas

Medical equipment: Micro injection systems for imaging equipment scanning institutions and laboratory analyzers;

Industrial automation: positioning module of high-speed surface mount machine, optical path adjustment mechanism of laser processing equipment;

Semiconductor manufacturing: high-precision transmission units for wafer handling robotic arms and packaging equipment;

Precision instruments: optical detection system stage, astronomical telescope tracking device.
