BENTLY 3500 22M 288055-01 Product Overview

The BENTLY 3500 22M 288055-01 module is a type of 3500 series transient data interface module(TDI),which is the interface between the 3500 monitoring system and compatible software.The module combines the functions of the 3500/20 rack interface module(RIM)and the data collection capabilities of a communication processor(such as TDXnet).It can continuously collect steady-state and transient dynamic(waveform)data and pass this data to the host software such as System 1 condition monitoring and diagnostic software through an Ethernet link.

Main Features

Vibration Monitoring

The module has high-precision vibration monitoring function and can monitor the vibration of the equipment in real time,including parameters such as vibration velocity,acceleration and displacement.

Capable of measuring vibration data from up to 8 sensors,supporting multiple sensor types such as accelerometers,velocimeters,and displacement sensors.

Fault diagnosis

By collecting and analyzing vibration data,the module can identify and diagnose mechanical faults such as bearing wear,imbalance,looseness,etc.

Timely alarms or triggering maintenance operations help users prevent equipment failures,reduce downtime and repair costs.

High reliability and stability

The module has high reliability and stability and is suitable for long-term operation in industrial environments.

It is manufactured with redundant design and high-quality materials to ensure normal operation under various harsh conditions.

Flexible configuration

The module provides a variety of configuration options and can be customized according to specific application requirements.

Including the number of input channels,sampling rate,alarm settings,etc.to meet the needs of different users.

Communication interface

The module has a variety of communication interfaces to support data interaction and integration with other monitoring systems or control systems.

Including 10Base-T or 100Base-TX Ethernet interface and 100Base-FX fiber-optic Ethernet interface,which is convenient for users to choose the appropriate communication method according to actual needs.

Scalability

This module supports modular design and can be combined with other Bently Nevada monitoring modules to build a more comprehensive monitoring system.

Users can increase or decrease the number of modules according to actual needs to meet monitoring needs of different scales.

Application Field

BENTLY 3500 22M 288055-01 module is widely used in various industrial automation and control system scenarios,such as power,oil and gas,chemical,manufacturing and other industries.In these industries,it is used to monitor the vibration of rotating mechanical equipment such as generators,steam turbines,compressors,pumps,machine tools,etc.,to help users detect equipment failures in time and take corresponding maintenance measures to ensure the normal operation and production efficiency of the equipment.

Technical Specifications

Dimensions:138x 138x 25mm(may vary slightly due to different manufacturers or batches)

Weight:According to different information,there are two possible weights,0.5kg and 1.2kg(the specific weight may vary due to manufacturers or batches)

Interface type:10Base-T/100Base-TX Ethernet interface,100Base-FX fiber optic Ethernet interface

LED indicator:used to indicate the operating status of the module,communication status,etc.

Other features:support rack reset button,OK relay indicates the OK status of the entire rack,etc.
