INTELLISCANDE14-405NM SCANLAB Controller: High-Precision Laser Scanning Solution

The INTELLISCANDE14-405NM is a cutting-edge laser scanning controller developed by SCANLAB GmbH, a leading provider of high-performance galvanometer scanners and laser control systems. Designed for precision laser processing applications, this controller combines advanced digital signal processing (DSP) and field-programmable gate array (FPGA) technologies to deliver unmatched speed, accuracy, and reliability.

Key Features

1. High-Speed Scanning Capabilities
   • Maximum Scanning Speed: Up to 10 m/s, enabling rapid laser processing in applications such as marking, welding, drilling, and micromachining.
   • Dynamic Performance: Optimized for high-speed motion with minimal tracking error (<0.15 ms), ensuring smooth and precise beam positioning.
2. High-Resolution Control
   • Positioning Resolution: Up to 20-bit (0.7 µrad for a ±0.36 rad angle range), enabling sub-micron-level precision.
   • Nonlinearity: <0.5 mrad/44°, ensuring consistent performance across the scanning field.
3. Wavelength Compatibility
   • Standard Wavelength Support: 405 nm (UV), with additional coatings available for YAG, fiber, green, UV, DUV, and CO₂ lasers, making it suitable for a wide range of laser systems.
4. Robust Design & Thermal Stability
   • Temperature Drift: Offset <15 µrad/K, Gain <8 ppm/K, ensuring long-term stability in industrial environments.
   • Cooling Options: Water or air cooling available, with an operating temperature range of 25 °C ± 10 °C.
5. Advanced Diagnostics & Connectivity
   • Real-Time Monitoring: Continuous monitoring of mirror position, velocity, drive current, voltage, and temperature for enhanced process control.
   • Communication Interfaces: Supports USB 2.0, RS232, and Ethernet, enabling seamless integration with industrial automation systems.
6. Enhanced Safety & Diagnostics
   • Protection Mechanisms: Overcurrent, overvoltage, and overtemperature protection ensure safe operation.
   • Remote Diagnostics: Supports remote access for monitoring and troubleshooting, reducing downtime.

Technical Specifications

• Dimensions (L × W × H): 300 mm × 200 mm × 100 mm
• Weight: 5 kg
• Power Supply: AC 220V/50Hz
• Max. Laser Power: 440 W @ 1064 nm (standard systems, 100% duty cycle)
• Typical Scan Angle: ±0.35 rad (opt.)
• Image Field Size: 95 mm × 95 mm (at 1064 nm, f = 160 mm)
• Typical Spot Size: 23 µm (at 1064 nm, f = 160 mm, M² = 1.0)
• Step Response Time: 0.45 ms (settling to 1/1000 of full scale)
• Repeatability (RMS): <0.4 µrad

Applications

The INTELLISCANDE14-405NM is ideal for:

• Laser Marking & Engraving
• Precision Welding & Cutting
• Micromachining & Drilling
• Rapid Prototyping & 3D Printing
• Photovoltaic Cell Production
• Medical Device Manufacturing

Software & Integration

• Control Software: Compatible with laserDESK, syncAXIS, and RTC boards for intuitive operation and advanced process control.
• Custom Tunings: Application-specific tunings available for optimized performance in specialized tasks.

Conclusion

The INTELLISCANDE14-405NM represents the pinnacle of laser scanning technology, offering unmatched speed, precision, and reliability for industrial laser processing. Its advanced features, robust design, and seamless integration capabilities make it the preferred choice for high-end manufacturing applications.

For more information, visit SCANLAB’s official website or contact a SCANLAB representative.
