Bently Nevada 135473-01 2 M-Series Proximity Probe Product Overview

The Bently Nevada 135473-01 2 M-Series Proximity Probe is a versatile and reliable sensor used for non-contacting vibration measurement in rotating machinery. It is designed to measure radial vibration of shafts, bearings, and other rotating components, providing valuable data for machinery protection and condition monitoring applications.

General Information

• Manufacturer Bently Nevada
• Part Number 135473-01 2
• Product Type M-Series Proximity Probe
• Series M-Series

Key Features

• Rugged Construction Features a robust stainless steel housing and a high-temperature ceramic tip, ensuring durability and resistance to harsh operating environments.
• Wide Temperature Range Operates in a wide temperature range from -40°C to 260°C (-40°F to 500°F), suitable for various machinery applications.
• High Sensitivity Provides high sensitivity for detecting even small vibration displacements, enabling accurate condition monitoring.
• Versatile Mounting Options Offers multiple mounting options, including threaded, stud, and adhesive mounting, to accommodate diverse installation requirements.

Applications

The Bently Nevada 135473-01 2 M-Series Proximity Probe finds extensive applications in various industries for machinery protection and condition monitoring, including

• Oil and gas
• Power generation
• Petrochemical
• Manufacturing
• Pulp and paper

Specifications

• Measurement Range 0 to 0.25 inches peak-to-peak
• Frequency Range 2 Hz to 20 kHz
• Sensitivity 10 mV/mil
• Output Impedance 500 Ω
• Power Requirements 24 VDC
• Operating Temperature -40°C to 260°C (-40°F to 500°F)
• Storage Temperature -40°C to 85°C (-40°F to 185°F)
• Humidity 95% non-condensing
• Dimensions 25.4 mm x 76.2 mm x 12.7 mm (1.00 in. x 3.00 in. x 0.50 in.)
• Weight 0.14 kg (0.31 lbs.)
