The Emerson KJ3001X1-BH1 Output Module is a high-performance device designed to deliver precise and reliable output signals in Emerson’s Intelligent Logic Solver (ILS) system. This module serves as a crucial interface between the control logic and actuators or field devices by converting internal control commands into electrical output signals. The KJ3001X1-BH1 supports multiple output channels, providing versatile control for a range of industrial automation applications.

Built for durability and consistent performance, the module ensures robust electrical isolation and protection features to safeguard both the system and connected devices. Its compact design and straightforward installation process make it an ideal choice for complex control panels requiring dependable digital or analog output capabilities.

Product Specifications

Product Applications

• Control of actuators, valves, and motors in industrial automation

• Process control output signal management

• Safety instrumented system (SIS) output interface

• Manufacturing line automation and machine control

• Power plant control systems

• Oil and gas process automation

• Water and wastewater treatment control

• HVAC system output control

• Renewable energy system management

• Remote output control in distributed automation networks

Product Advantages

• Reliable Output Performance: Delivers stable and accurate output signals for critical control functions.

• Robust Electrical Isolation: Protects control logic from electrical noise and faults in the output circuits.

• Compact and Space-Saving: Efficient design suitable for dense control panel installations.

• Easy Integration: Seamless compatibility with Emerson ILS systems and communication protocols.

• High Durability: Designed to operate reliably across a wide temperature range and industrial environments.

• Quick Installation: DIN rail mounting and standardized connectors facilitate rapid setup.

• Flexible Output Channels: Supports multiple output types suitable for diverse applications.

• Safety Certified: Meets global standards including CE and UL for electrical safety.

• Low Maintenance: Minimal upkeep required due to rugged design.

• Improved System Uptime: Reduces downtime through reliable hardware performance.

Frequently Asked Questions (FAQ)

1. What type of outputs does the KJ3001X1-BH1 support?

   The module supports relay or transistor outputs depending on the specific version.

2. How many output channels are available on this module?

   It provides 8 output channels.

3. What is the maximum output current per channel?

   Each output channel can handle up to 0.5 A typically.

4. What voltage level does the module operate with?

   It typically operates at 24 V DC for output signals.

5. Can the module be installed on standard DIN rails?

   Yes, it is designed for DIN rail mounting.

6. What is the operating temperature range of the module?

   The module operates between -20°C and +70°C.

7. Is the module compatible with Emerson Intelligent Logic Solver systems?

   Yes, it fully integrates with Emerson ILS communication protocols.

8. What safety certifications does the module have?

   It is CE certified and UL recognized.

9. How is electrical isolation achieved in this module?

   Optical isolation is provided between output circuits and logic to prevent interference.

10. What maintenance is required for the KJ3001X1-BH1?

    The module requires minimal maintenance; routine inspections for connection integrity are recommended.
